The technical realization elements of the manufacturing method of the pharmacy drug storage device

Technical realization elements:

4. In order to solve the above-mentioned various problems, the utility model proposes a pharmacy medicine storage device that can be refrigerated, clearly classified, and saves space.

5. In order to solve the above technical problems, the technical solution proposed by the present utility model is: a pharmacy drug storage device, including a storage cabinet, the lower end of the storage cabinet is connected with a refrigerating box, and the front of the refrigerating box passes through a hinge A refrigerating box door is provided in a rotating connection, a refrigerating machine is fixedly connected to one side of the inner bottom surface of the refrigerating box by bolts, and a transmission tube is connected to the refrigerating machine, and the transmission tube is fixed to the refrigerating box by bolts On the inner and rear side walls, a number of drawers are connected in the middle of the storage cabinet, a baffle is connected in the drawer, and a sorting storage compartment is connected between the baffle and the side wall of the drawer. The sorting storage room and the side wall of the drawer are connected with a cover plate through a hinge rotation, a label bag is glued on the cover plate, a normal temperature box is connected to the upper end of the storage cabinet, and the front of the normal temperature box passes A room temperature box door is arranged in the hinge rotation connection, and a number of room temperature storage rooms are slidably provided in the room temperature box. A sliding rail matching the sliding bar is arranged on the bottom surface of the normal temperature box.

6. Further, the group of normal temperature storage rooms on the front side has a smaller number than the group of normal temperature storage rooms on the rear side.

7. Further, a desiccant is provided in the baffle, and a plurality of through holes are provided on the side of the baffle.

8. Further, the transmission tube is a multi-section U-shaped tube.

9. Further, the cover, the drawer, the refrigerator door, the normal temperature box door, and the normal temperature storage room are all connected with handles.

10. Compared with the prior art, the utility model has the advantages that: when the utility model is used, multiple parts that need to be opened manually are connected with handles, which is more convenient for opening and closing the doors of various boxes; if there are medicines that need to be refrigerated and stored , Turn on the refrigerator to cool down the refrigerator, to maximize the effectiveness of the medicine and avoid failure; there is a sorted storage compartment in the drawer, and similar medicines can be sorted into each sorted storage compartment, and the cover is equipped with The label bag can introduce the efficacy of the medicine in detail; the normal temperature box stores common medicines, and the normal temperature storage room on the front side is less than the rear side, so that it is easy to slide in the slide rail and expose the room temperature storage room on the rear side. Increase space utilization.
