Technical Realization Elements Of Intelligent Positioning Device Used For Civil Air Defense Door Installation

Technical implementation elements:

5. The purpose of the present invention is to provide a kind of intelligent positioning device for the installation of civil air defense doors, in order to solve the above-mentioned background technology, the installation process of the door leaf is usually carried out by means of hoisting, and the position of the door leaf needs to be adjusted for a long time. Only then can the door leaf and the hinge on the door frame be aligned, which makes the installation process cumbersome.

6. In order to achieve the above purpose, the present invention provides the following technical solutions: a kind of intelligent positioning device for the installation of civil air defense doors, comprising a No. 1 board, and both ends of the No. 1 board are The bottom end of the second plate is provided with more than two moving wheels. The moving wheels have a self-locking structure. Both ends of the two second plates are provided with vertical through holes, and the through holes are fixed at the through holes. There is a drive motor, the output shaft of the drive motor is directed downward, the output shaft end of the drive motor is fixed with a screw rod, the bottom end of the screw rod is threadedly connected with a lifting plate, and the top end of the lifting plate is along its length. There are more than two rollers equidistant in the direction, and one end of the second plate away from the first plate is fixed with the third plate, and the top of the third plate is fixed with a positioning mechanism, and the positioning mechanism is used for human defense. For the positioning of the door, the positioning mechanism is provided with a controller, and the controller is used to control the operation of the positioning mechanism.
