Manufacturing Method Of Intelligent Positioning Device For Installation Of Civil Air Defense Door

1. The present invention relates to the technical field of air defense door installation, in particular to an intelligent positioning device used for air defense door installation.

Background technique:

2. Civil air defense doors are the entrances and exits of people's protection projects. The classification of civil air defense doors is relatively clear. There are ordinary single and double-leaf protective airtight doors and airtight doors, and single and double-leaf protective airtight doors and airtight doors.

3. There are also some technical solutions about the installation of civil air defense doors in the prior art, such as a Chinese patent with the application number of cn202010685320.0, which discloses a positioning support device for civil air defense doors. Place the first mounting plate and the second mounting plate respectively, and screw the threaded rod to make the abutting block abut and fix the panels placed on the first mounting plate and the second mounting plate, and then drive the first mounting plate through the moving assembly and the second mounting plate move in the direction of approaching each other, so that the two panels are spliced together, so that it is convenient for the staff to weld the panels. It is not easy to shake, which is beneficial to improve the forming quality of the air defense door welding. At the same time, the lifting mechanism drives the support plate to lift and lower, so that the staff can weld the air defense door at different heights, thereby improving the applicability of the device; however, this patent cannot The installation of the door leaf is usually carried out by means of hoisting, and the position of the door leaf needs to be adjusted for a long time to make the door leaf and the hinge on the door frame align, which makes the installation process cumbersome.

4. Based on this, the present invention designs an intelligent positioning device for the installation of civil air defense doors to solve the above problems.
