The technical realization elements of the steel pin pre-socket device

Technical implementation elements:

4. The present utility model provides a steel needle pre-insertion device, which solves the problem of inconvenient installation of the thermal insulation board because most of the existing thermal insulation board pre-pinning devices can only insert pins into the thermal insulation board once. The effect of secondary pre-pinning of the insulation board is achieved, and the effect of quickly and automatically removing debris is achieved.

5. In order to solve the above-mentioned technical problems, the utility model provides a steel needle pre-socket device, which includes an installation bottom box, a needle insertion mechanism and a cleaning mechanism;

6. The pin insertion mechanism includes a fixed frame, a fixed block, a guide rod, a rack, a pre-pinned machine, an adjustment frame, a servo motor, two electric telescopic rods, two mounting plates, two rotating shafts and two gears , the fixing frame is fixedly connected to the rear side of the top of the installation bottom box, the interior of the fixing frame is provided with a fixing cavity, the two electric telescopic rods are symmetrically and fixedly connected in the fixing cavity, and the driving end of the electric telescopic rod Through the fixing frame, the fixing block is fixedly connected to the driving end of the electric telescopic rod, the two mounting plates are symmetrically and fixedly connected to the front side of the fixing block, and the guide rod is fixedly connected to the opposite side of the two mounting plates, The rack is slidably sleeved on the guide rod, the pre-pin machine is fixedly connected to the front side of the rack, the adjusting frame is fixedly connected to the top of the front side of the fixed block, and the inside of the adjusting frame is provided with a sliding The bottom of the adjusting frame is provided with a fixing port, the fixing port is connected with the sliding cavity, the two rotating axes are symmetrically connected in the adjusting frame, and the two gears are respectively fixed and sleeved on the two rotating shafts. On the shaft, and the gear is meshed with the rack, the servo motor is fixedly connected to the front side of the adjustment frame, and the drive shaft of the servo motor is drivingly connected to one end of one of the rotating shafts. rod to extend or shorten the driving end of the two electric telescopic rods to adjust the position of the fixed block, and then turn on the servo motor, so that one of the rotating shafts drives one of the gears to rotate, and the rack drives the pre-pinning machine along the guide rod. Move the adjustment position horizontally in the direction, and then turn on the pre-pinning machine to make the pre-pinning machine enter the insulation wall panel placed on the top of the workbench.

According to the above adjustment of the position of the pre-pinning machine, the thermal insulation wallboard can be subjected to secondary pre-pinning processing. To sum up, it solves the problem that most of the existing thermal insulation board pre-pinning devices can only be used for thermal insulation. The single pin insertion of the board leads to the problem of inconvenient installation of the insulation board, and the effect of secondary pre-pinning of the insulation board is realized.

7. Preferably, the cleaning mechanism includes a sliding plate, a transmission shaft, a cam, a drive motor, a workbench, two bellows and two support columns, and the two bellows are symmetrically arranged at the bottom of the front side of the fixed frame, and the installation An installation cavity is arranged inside the bottom box, the slide plate is slidably connected in the installation cavity, the two support columns are symmetrically and fixedly connected to the top of the slide plate, the workbench is located above the installation bottom box, and the top of the support column It penetrates through the installation bottom box and is fixedly connected to the bottom of the workbench, the transmission shaft is fixedly rotatably connected in the installation bottom box, the cam is fixedly sleeved on the transmission shaft, and the cam is matched with the bottom of the slide plate. The drive motor is fixedly connected to the rear side of the installation bottom box, and the drive shaft of the drive motor is drive-connected to one end of the drive shaft. By turning on the drive motor, the drive shaft drives the cam to rotate, so that the cam pushes the slide plate to drive the support column to move vertically upward. , when the top of the slide plate is in contact with the inner top wall of the installation bottom box, open the bellows, so that the blowing fan blows the debris left on the top of the installation bottom box out of the installation bottom box. In summary, the existing thermal insulation problem is solved. Most of the board pre-pin devices are not provided with a cleaning mechanism, which leads to the problem that the debris left on the top of the device affects the subsequent processing of the insulation board, and the effect of quickly and automatically removing the debris is achieved.

8. Preferably, sprockets are fixedly sleeved on the two rotating shafts, and a transmission chain is meshed and connected to the two sprockets. Since the sprockets and the transmission chain are provided, the two gears rotate simultaneously.

9. Preferably, both sides of the top of the workbench are integrally formed with protective ledges, one side of one of the protective ledges is threadedly connected with a positioning bolt, and the end of the positioning bolt penetrates the protective ledge and is fixed. Clamping plates are attached to position insulation plates of different volumes on top of the workbench.

10. Preferably, the front side of the bellows is provided with a blowing slot, and an air blowing fan is arranged in the blowing slot, and a battery is fixedly connected to the rear side of the fixing frame, and the battery is electrically connected to the blowing fan, Continuously powers the blower fan.

11. Preferably, baffles are fixedly connected to both sides of the top of the installation bottom box, and the worktable is slidably connected to the opposite side of the two baffles to prevent the debris side from sliding down to the side of the installation bottom box, This makes it inconvenient for staff to perform centralized cleaning.

12. Preferably, a control board is provided on one side of the installation bottom box, and the control board is electrically connected to the electric telescopic rod, the drive motor and the servo motor. , servo motor and drive motor for control.

13. Preferably, the bottom four corners of the installation bottom box are fixedly connected with support legs.

14. Compared with the related art, a steel needle pre-socket device provided by the present invention has the following beneficial effects:

15.1. In this utility model, by opening two electric telescopic rods at the same time, the driving ends of the two electric telescopic rods are extended or shortened to adjust the position of the fixed block, and then the servo motor is turned on, so that one of the rotating shafts drives one of the gears to rotate. , Due to the setting of the sprocket and the transmission chain, the two gears rotate at the same time, the rack drives the pre-pinning machine to move horizontally along the direction of the guide rod to adjust the position, and then the pre-pinning machine is turned on to make the pre-pinning machine face the worktable. The thermal insulation wall panel placed on the top is pre-pinned. According to the above adjustment of the position of the pre-pin machine, the thermal insulation wall board can be pre-pinned for the second time. In summary, the existing thermal insulation board pre-pin device is solved. Because most of the insulation boards can only be inserted into the insulation board once, which leads to the problem of inconvenient installation of the insulation board, the effect of pre-pinning the insulation board for a second time is realized. By rotating the positioning bolt, the positioning bolt drives the clamping plate to follow. It rotates and moves horizontally to position the insulation boards of different volumes on the top of the workbench.

16.2. In this utility model, by turning on the drive motor, the drive shaft drives the cam to rotate, so that the cam pushes the slide plate.

Drive the support column to move vertically upward. When the top of the slide plate is in contact with the inner top wall of the installation bottom box, open the bellows, so that the blowing fan blows the debris left on the top of the installation bottom box out of the installation bottom box. To sum up the above , solves the problem that most of the existing insulation board pre-pin devices are not provided with a cleaning mechanism, resulting in debris left on the top of the device affecting subsequent insulation board processing, and achieves the effect of quickly and automatically removing debris, By setting the control board, it is convenient for the staff to control the electric telescopic rod, the servo motor and the drive motor.
