Technical realization elements of dust removal device for slitting machine

Technical implementation elements:

4. The purpose of the present utility model is to provide a dust removal device for a slitting machine, so as to solve the problem that the dust removal device of the slitting machine only cleans up the dust when in use, and cannot process the dust and discharge the dust. The gas still contains dust and impurities, causing certain pollution to the environment.

5. In order to achieve the above purpose, the present utility model provides the following technical solutions: a dust removal device for a slitting machine, comprising: a slitting machine body, and a dust collecting hood is provided on the left side of the slitting machine body;

6. A processing box, which is arranged on the left side of the dust collecting hood, and a connecting pipe is arranged above the processing box;

7. A water pump, which is arranged on the outer wall of the connecting pipe;

8. A water tank, which is arranged on one side of the connecting pipe;

9. A fan, which is arranged inside the dust hood;

10. An activated carbon filter screen, which is arranged on the outer wall of the treatment box;

11. An ash hopper, which is arranged below the processing box;

12. A filter bag holder, which is arranged inside the treatment box, and a filter bag is installed on the inner side of the filter bag holder;

13. A pin, which is arranged on the outer wall of the slitter body, and a connecting rod is arranged above the pin;

14. A light board, which is arranged at the front end of the connecting rod;

15. A hand rocker, which is arranged on the outer wall of the connecting rod, and a connecting shaft is provided on the right side of the hand rocker;

16. A cleaning roller, which is provided on the right side of the connecting shaft.

17. Preferably, the activated carbon filter screen and the treatment box are fitted with each other, and the activated carbon filter screen is evenly distributed at equal distances along the outer wall of the treatment box.

18. Preferably, the filter bag holder and the treatment box are welded and connected, and a detachable structure is formed between the filter bag and the filter bag holder.

19. Preferably, a rotating structure is formed between the connecting rod and the body of the slitting machine through a pin, and the pin and the body of the slitting machine are connected by a pin connection.

20. Preferably, the hand rocker forms a rotating structure between the connecting shaft and the cleaning roller, and between the connecting shaft and the cleaning roller

for solder connections.

21. Preferably, the connecting pipe is further provided with:

22. A water collecting pan, which is arranged on the other side of the connecting pipe, and the outer wall of the water collecting pan is provided with a spray head.

23. Preferably, the spray heads are evenly distributed along the outer wall of the water collecting pan, and a communication structure is formed between the spray heads passing through the water collecting pan and the connecting pipe.

24. Compared with the prior art, the present utility model provides a dust removal device for a slitting machine, which has the following beneficial effects: the dust removal device for a slitting machine can remove the collected dust during use. Carry out certain filtration treatment to avoid the exhaust gas still containing dust and pollute the environment.

25.1. The installed activated carbon filter can adsorb and filter the discharged clean air, so as to prevent the discharged gas from containing peculiar smell and ensure the cleanliness of the gas; The dust mixture is filtered, and the filter bag can filter the dust in the gas, so that the clean air is discharged through the activated carbon filter, so as to prevent the dust and impurities in the discharged gas from polluting the environment.

26.2. When the connecting rod is provided, the outer wall of the slitter body can be rotated under the action of external force under the driving of the pin, so that the cleaning roller can be rotated to a suitable angle according to the needs of use. The surface of different collection rollers is cleaned; the cleaning roller can be rotated under the joint action of the hand rocker and the connecting shaft, so that it can contact with the collection roller on the main body of the slitting machine, and the dust adhered to its surface Carry out adsorption cleaning.

27.3. Through the set nozzle, the water in the water tank can enter the nozzle through the connecting pipe and the water collecting tray, so that the water flow can be evenly sprayed on the inside of the processing box through the nozzle, so that the dust can be combined with the water mist to remove the dust. Settlement treatment.
