Technical realization elements of large shaft toilet paper cutting device

Technical realization elements:

5. In order to solve the above technical problems, a large-axis toilet paper cutting device is provided. This technical solution solves the above-mentioned background art that the cutting table does not have an automatic expansion device and the cutting table does not have a fixing device.

6. In order to achieve the above purpose, the technical scheme adopted by this utility model is:

7. A large-axis toilet paper cutting device, comprising an operation center, the bottom of the operation center is fixedly connected with a cutting assembly, the bottom of the operation center is fixedly connected to the top of a support base near the edge of one side of the outer wall, the support base One side of the outer wall of the control center is fixedly connected to one side of the control center, and one side of the control center is fixedly installed with a power key. The edge of one side of the outer wall of the support base is fixedly connected to the fixed end of the photoelectric sensor. The sensor is electrically connected to the control center, the upper surface of the convex platform extending outward of the support base is fixedly connected to the bottom of the telescopic assembly near the edge of the outer wall, and one outer wall of the support base is connected to one outer wall of the workbench In a fixed connection, the bottom of the worktable is fixedly connected with the top of the column, the number of the column is multiple, and each column is rectangular.

8. Preferably, the interior of the workbench is provided with a groove, the middle of the inner wall of one side of the workbench is fixedly connected to the bottom of the sliding platform, and the other side wall of the sliding platform is connected to one side of the support seat The edge of the outer wall is fixedly connected.

9. Preferably, the inner wall of the telescopic assembly is fixedly connected to the fixed end of the first electric push rod, the output end of the first electric push rod is fixedly connected to one side outer wall of the telescopic table, and the first electric push rod Electrically connected to the control center, a cutting groove is formed on the upper surface of the telescopic table near the edge, and the cutting groove and the cutting assembly are matched with each other.

10. Preferably, the bosses extending outward from the upper surface of the telescopic table are fixedly connected to the bottom of the fixing component, and one end of the telescopic table is fixedly connected with the pushing component near the edge of one side of the outer wall.

11. Preferably, the inner wall of the fixing assembly is fixedly connected to the fixed end of the second electric push rod, the output end of the second electric push rod is fixedly connected to one side outer wall of the fixed plate, and the length of the fixed plate is different. Beyond the cutting assembly, the second electric push rod is electrically connected to the control center.

12. Preferably, the inner wall of the pushing assembly is fixedly connected to the fixed end of the third electric push rod, and the third electric push rod

The output end of the push rod is fixedly connected with the middle part of one side outer wall of the push plate, and the third electric push rod is electrically connected with the control center.

13. Compared with the prior art, the utility model provides a large shaft toilet paper cutting device, which has the following beneficial effects:

14.1. The first electric push rod fixedly connected to the first electric push rod is fixedly connected to a side wall of the telescopic table by the output end of the first electric push rod by arranging the inner wall of the telescopic assembly. , The information is transmitted to the control center, and then the control center controls the first electric push rod to work. During the expansion and contraction of the first electric push rod, it is convenient for the toilet paper on the telescopic table to be cut, thereby realizing the workbench installation for cutting. There is an automatic telescopic device.

15.2. The second electric push rod is fixedly connected by the inner wall of the fixed assembly through the fixed assembly provided on the telescopic table. The output end of the second electric push rod is fixedly connected with a fixed plate. When the photoelectric sensor detects the telescopic table When using toilet paper, the information is transmitted to the control center, and then the control center controls the second electric push rod to work. When the second electric push rod pushes the fixing plate forward, it has the effect of fixing the toilet paper, thus realizing the cutting work Fixing devices are installed on the stage.
