Technical realization elements of insulation pipe cutting device

Technical implementation elements:

3. The purpose of this utility model is to provide a thermal insulation pipe cutting device to solve the problem that when the existing thermal insulation pipe is cut, a large amount of cutting waste will be produced. The cutting device cannot effectively collect and process the cut waste, which brings great inconvenience to the user's operation.

4. the purpose of the present utility model is achieved through the following technical solutions:

5. A thermal insulation pipe cutting device, comprising a cutting table, a cutting device and a dust cover, the dust cover is arranged at the top of the cutting table, and both ends of the dust cover along its length direction are open ; The cutting device is arranged in the inner cavity of the dust cover, and includes a cutting wheel, a rotating shaft, a motor and a support plate, one end of the rotating shaft is connected with the motor, and the other end passes through the support plate and is connected to the motor. the cutting wheel is connected;

6. A first air cylinder is arranged on the top wall of the inner cavity of the dust cover, and the piston rod of the first air cylinder is connected to the top end of the support plate; The top end of the chip collecting cavity penetrates through the cutting table, and a first filter screen is embedded in the penetration part.

7. Preferably, a chip outlet communicating with the chip collecting chamber is provided along one end of the chip collecting chamber along the width direction thereof.

8. Preferably, the chip outlet is provided with a door hinged to its top end.

9. Preferably, the bottom end of the chip collecting chamber is provided with a scraper that is slidably connected to it, and one end of the scraper along its length direction is provided with a chute, and the inner wall of the chip collecting chamber is provided with a scraper. A sliding plate matched with the chute, the sliding plate is arranged along the width direction of the chip collecting cavity.

10. Preferably, one end of the scraper facing the chip outlet is provided with a pull rod, and the pull rod is disposed along the thickness direction of the scraper.

11. Preferably, two openings along the length of the dust cover are embedded with a second filter screen, and the two second filter screens are respectively provided with an inlet port and an outlet port.

12. Preferably, protection pads are embedded on the inner walls of the inlet and outlet, and the protection pads are made of elastic materials.

13. Preferably, the first filter screen is also provided with a clamping device, the clamping device includes two clamping plates, and the two clamping plates are arranged at intervals along the width direction of the first filter screen, and are dust-proof. Both ends of the cover along its width direction are respectively provided with second cylinders, and the piston rods of the two second cylinders respectively pass through the outer wall of the dust cover, and both are respectively

Connect with both of the splints.

14. The utility model has at least one of the following advantages:

15. In this utility model, a workbench, a dust cover, a cutting device, a first air cylinder, a chip collecting chamber and a first filter screen are provided. Inside the cover, then start the first cylinder and the cutting device, the first cylinder drives the cutting device to gradually descend to cut the insulation pipe, most of the slag splashed during the cutting process is covered by the dust cover, and most of the slag The chips fall into the chip collecting cavity through the first filter screen, so that the staff can collect them easily. Therefore, the utility model can prevent most of the slag from splashing out of the workbench, and most of the slag passes through the first filter screen and then falls into the chip-collecting cavity, which is convenient for the staff to deal with in a centralized manner.
