Manufacturing method of jig material tray lifting platform with limit mechanism

1. The utility model relates to the technical field of jig auxiliary devices, specifically a jig material tray lifting platform with a limit mechanism.

Background technique:

2. Fixture is a tool of woodwork, ironwork, fitter, machinery, electric control and some other handicrafts. It is mainly used as a tool to assist in controlling position or movement. Jigs can be divided into three types: process assembly jigs, project test jigs and circuit board test jigs.

3. The existing jig material tray needs to be installed on the lifting platform when in use, which is convenient to adjust the distance between the jig material tray and the ground, and is suitable for workers of different heights. The existing lifting platform usually uses clamps Fixing the jig material plate, the fixing effect is not good, the jig material plate may shake up and down during the operation of the staff, which affects the work efficiency of the staff.

4. Based on this, the utility model designs a jig material tray lifting platform with a limit mechanism to solve the above problems.
