Technical realization elements of anti-tilt mold frame

Technical realization elements:

3. The main purpose of the present utility model is to provide an anti-tilting mold frame, which can effectively solve the problems in the background art.

4. In order to achieve the above-mentioned purpose, the technical scheme adopted by this utility model is:

5. An anti-tilt mold frame, comprising a load-bearing frame body, the load-bearing frame body including a main pillar, a reinforcement bar, a load-bearing main rod, a connecting rod shaft and a movable bearing, and a connecting structure is movably installed on the inner side of the load-bearing frame, The connecting structure includes a center-of-gravity connecting rod, a bearing mounting groove, an installation connecting rod, and a mounting block. The lower end of the connecting structure is fixedly welded and installed with an anti-falling suspension foot. The anti-falling suspension foot includes a suspension rod, a widening rod, a grounding pillar, and For the grounding pin, a mold placement board is fixedly installed on the inner side of the connecting structure, and the mold placement board includes a main board, a soft block installation slot, a customized fixed soft block, and a mold placement slot.

6. Preferably, there are two groups of the main pillars, and the number of each group is two. The main pillars are fixedly welded and installed with reinforcement bars adjacent to the main pillars, and the load-bearing main rods are fixedly welded and installed on the reinforcement bars. A connecting rod shaft is fixedly welded on one side of the load-bearing main rod, and the side surface of the connecting rod shaft is fixedly welded to the inner ring of the movable bearing.

7. Preferably, the upper end of the rear side surface of the center of gravity connecting rod is provided with a bearing installation groove, the two sides of the center of gravity connecting rod are fixedly welded and installed with mounting connecting rods, and one end of the mounting connecting rod is fixedly welded and installed with a mounting plate block.

8. Preferably, widening rods are fixedly welded and installed on both sides of the suspension rod, one end of the widening rod is fixedly welded and installed with a grounding pillar, and the lower end of the grounding pillar is fixedly welded and installed with a grounding foot.

9. Preferably, the upper surface of the storage main board is provided with a soft block installation groove, a custom fixed soft block is movably installed in the soft block installation groove, and a mold placement groove is opened on the upper surface of the custom fixed soft block.

10. Preferably, the movable bearing outer ring is fixedly installed in the bearing installation groove, the lower end of the center of gravity connecting rod is fixedly welded and installed with a suspension rod, and one side of the mounting block is fixedly welded and installed with a storage main board.

11. Compared with the prior art, the utility model has the following beneficial effects:

12. In the present utility model, the mold is placed in the mold placement groove on the upper surface of the customized fixed soft block, and the customized fixed soft block is placed in the mold placement groove on the upper surface of the storage main board, and the center of gravity of the mold placement board is always adjusted through the connection structure. Downward, when the storage board shakes, gravity is used to keep the storage board level at all times to prevent it from tilting. At the same time, the custom fixed soft block and mold placement slot will always fix the mold. When placed accidentally tilted, the mold will collide or be removed from the storage board. The surface slides down. When the load-bearing frame body is affected by external forces and has a tendency to fall, the gravity link will drive the anti-fall suspension foot to rotate in the tipping direction under the action of gravity. The suspension rod is always vertical to the ground until the grounding foot touches the ground. Grounding pillar, expansion

The wide rod, the suspension rod and the center of gravity connecting rod form a pillar structure to prop up the load-bearing frame to prevent it from falling and protect the mold
