Elements of Technical Realization of Fixtures for Auto Parts

Technical implementation elements:

3. Based on the technical problems existing in the background technology, the utility model proposes a fixture for automobile parts.

4. A clamp for automobile parts, comprising a mounting plate, a sliding plate and two clamping bars, the sliding plate is slidably mounted on the mounting plate, the sliding plate is provided with a chute, and the two clamping bars are relatively slidably installed on the mounting plate. In the chute, a plurality of elastic connecting pieces for approaching each other are arranged between the two clamping rods.

5. Preferably, the mounting plate is provided with a moving groove, the sliding plate is provided with a sliding block, and the sliding block is slidably installed in the moving groove.

6. Preferably, a rotating rod is rotatably connected to the mounting plate, and the rotating rod penetrates the sliding plate, one end of the rotating rod close to the clamping rod is provided with a cam, and a top rod is provided between the two clamping rods, The cam is located between the two jacks.

7. Preferably, the end of the turning rod away from the clamping rod is provided with a turning wheel, the turning wheel is provided with a turning handle, the turning wheel is provided with a clamping rod, and the sliding plate is provided with two limit positions. piece.

8. Preferably, the elastic connector includes two sleeves and a spring, a sliding rod is slidably installed in the two sleeves, the spring is sleeved outside the sliding rod, and the two ends of the spring are respectively connected with the two sleeves. connect.

9. Preferably, the two clamping rods are provided with clamping blocks, the two clamping blocks are located on one side of the two clamping rods close to each other, and the two clamping blocks are provided with soft pads on one side close to each other.

10. A clamp for automobile parts proposed by the present utility model, the spring drives two sleeves to approach each other, and the two sleeves drive two clamping rods to approach each other, so that the two clamping rods clamp the automobile parts; The two sleeves slide along the sliding rod, and the sliding rod guides the two sleeves for stable clamping; the sliding plate is installed in the moving groove through the sliding block, which can drive the clamping rod and the automobile parts to move, so as to facilitate the The next step of the operation of the auto parts; the runner drives the rotating rod and the cam to rotate, so that the two ejector rods are far away from each other, which is convenient for the loosening of the clamp; the clamp not only facilitates the clamping and fixing of the auto parts, simplifies the structure, but also facilitates clamping The held car parts can move stably, the operation is simple, and the car parts can be easily clamped and released, which enhances the practicability
