Elements of Technical Realization of Double Feeding Device for Modified Engineering Plastics

Technical implementation elements:

3. The purpose of the present utility model is to provide a modified engineering plastics double feeding device to solve the problems raised in the above-mentioned background technology.

4. In order to achieve the above purpose, the present utility model provides the following technical solutions: a modified engineering plastic double feeding device, comprising a processing box, the interior of the processing box is fixedly connected to a horizontal plate, and the bottom surface of the horizontal plate is fixedly connected to a motor. 1. The output end of the motor 1 is driven to connect the strut that penetrates the horizontal plate, the outer surface of the strut is evenly connected to the cutting knife, and the top of the processing box is provided with rectangular holes in symmetrical positions on the left and right sides. The inside of the hole is fixedly connected to one end of the feeding box, the upper surface of the feeding box is provided with two circular holes penetrating the interior of the feeding box, the inner walls of the left and right sides of the circular holes are respectively provided with chute, the A slider is set inside, one side of the slider is fixedly connected to the spring, one end of the spring is fixedly connected to the inner wall of the chute, one side of the slider is fixedly connected to the circular plate, and the bottom surface of the circular plate is fixedly connected to the conical rod The upper surface of the circular plate is provided with a through hole matching the diameter of the bottom surface of the conical rod, and the inner wall of one end of the conical rod is fixedly connected with elastic cotton.

5. Preferably, the bottom end of the outer surface of the processing box is fixedly connected to the second motor, the output end of the second motor is drivingly connected to a cylindrical rod running through the inner wall of one side of the processing box, and one end of the cylindrical rod is rotated and connected to the processing box through a bearing. On the inner wall of the other side, the outer surface of the cylindrical rod is fixedly connected to the spiral plate, which can conveniently push the cut product through the spiral plate for unloading, so as to complete the unloading of the product.

6. Preferably, the bottom surface of the processing box is fixedly connected to the support legs, and the inner bottom side of the processing box is provided with a discharge port, which is convenient for unloading the product and also convenient for collecting it.

7. Preferably, the outer surface of the processing box is provided with heat dissipation holes at the positions corresponding to the first motor, which can dissipate heat to the first motor, and avoid damage to the first motor caused by high temperature and affect the use.

8. Preferably, the circular hole inside the feeding box corresponds to the position of the cutting knife, and the cutting knife is fixedly installed on the outer surface of the support rod, which is convenient for the product to extend from the inside of the circular hole to the position of the cutting knife, which is convenient for passing through. The cutting knife cuts off the product.

9. Preferably, the round holes on the outer surface of the open rectangular bin correspond to the connection holes on the side of the power supply body respectively.

10. The technical effects and advantages of the present utility model: a modified engineering plastic double feeding device, by arranging a motor 1 inside the processing box, and setting a cutting knife at the output end of the motor 1, it can facilitate the processing of the whole plastic. Rod cutting, by setting two feeding boxes on the top of the processing box, it is convenient to process multiple products at a time, by setting a circular hole inside the feeding box, and setting a slidable circular plate inside the circular hole, the The tapered rod can be set to limit the position of the product, so that the product is always vertically downward, so as to facilitate its processing. By setting the spiral plate, it is convenient to unload the material. The device can pass through the two feeding boxes at the same time.

Feeding, improve work efficiency, save time, reduce the labor intensity of staff, easy and simple to operate.
