Elements of Technical Realization of Die for Modified Recycled Special Material

Technical implementation elements:

4. The purpose of the present utility model is to provide a special dicing die for modified and regenerated materials to solve the problems raised in the above-mentioned background technology.

5. In order to achieve the above purpose, the utility model provides the following technical solutions: a special-purpose material cutting die for modified regeneration, comprising a processing table, a bottom mold is fixedly connected at the middle position of the upper end of the processing table, and the upper end of the processing table is An outer frame is fixedly connected to the outer side of the upper end of the bottom mold, a cutting die is slidably connected inside the outer frame, a hydraulic cylinder is fixedly connected between the upper end of the cutting die and the upper end side wall of the outer frame, and the four corners of the lower end of the cutting die are connected. Each of them is fixedly connected with a limit rod, the upper end of the bottom mold is provided with a limit groove at the four corners, the lower end of the limit rod is slidably connected in the limit groove, and a block slot is opened in the middle of the bottom mold. , a feeding mechanism is arranged on the upper end of the bottom mold and at a position corresponding to the limit hole.

6. Preferably, the feeding mechanism includes a feeding trough, a linkage groove and a gear plate, the feeding troughs are all opened on the upper end of the bottom mold and are located on the side close to the limit hole, and the linkage groove is opened on the feeding trough. The side wall of the groove is corresponding to the position of the limit hole, a fixed rotating shaft is rotatably connected between the linkage groove and the feeding groove, and a feeding runner is fixedly connected on the fixed rotating shaft and located in the feeding groove. A non-slip sleeve is fixedly connected to the upper end of the feeding runner.

7. Preferably, a linkage gear is fixedly connected to the fixed rotating shaft and located in the linkage groove, and the outer side of the linkage gear passes through the linkage groove and is located in the limiting hole.

8. Preferably, a one-way bearing is fixedly connected at the connection between the linkage gear and the fixed rotating shaft, the outer side of the one-way bearing outer ring is fixedly connected in the linkage gear, and the inner side of the one-way bearing inner ring is fixedly connected to the fixed rotating shaft. superior.

9. Preferably, the gear plate is fixedly connected to the side of the limit rod close to the linkage groove, and the gear plate is meshed with the linkage gear.

10. Preferably, a material storage frame is clamped at the lower end of the processing table and at a position corresponding to the dicing groove, and a support frame is fixedly connected to both ends of the processing table.

11. Compared with the prior art, the beneficial effect of the present utility model is: during the upward movement of the cutting die to drive the limit rod to slide, through the transmission of the linkage gear of the feeding mechanism and the gear plate, the fixed rotating shaft can drive the feeding. The runner rotates, thereby driving the material between the bottom die and the cutting die to slide to one side, realizing automatic feeding and avoiding the troublesome operation of manual feeding.
