Damping fastening structure for sliding support and manufacturing method of sliding support

1. This utility model relates to sliding braces for building doors and windows, in particular to a damping fastening structure and sliding braces for sliding braces.

Background technique:

2. Sliding braces are used to connect window frames and window sashes, support window sashes, and realize a multi-rod device that rotates to the outside and opens in translation at the same time. It is widely used in building doors and windows.

3. The traditional sliding support includes the bottom groove fixed on the door and window frame, the supporting arm fixed on the door and window, the force receiving arm connecting the bottom groove and the supporting arm, and the guide arm connecting the bottom groove and the supporting arm. Add a plastic gasket on the top and bottom of one end of the guide arm, and then fasten the guide arm and the bottom groove with rivets, or fasten the guide arm and supporting arm with rivets. Because the sliding support has a long guide arm and high flexibility, it is easy to automatically open or close the window due to wind and other factors. The sliding support is prone to shaking during the opening and closing process, and the stability is poor.

4. The above shortcomings need to be improved.
