The technical realization elements of the intelligent welcome reception robot

Technical implementation elements:

4. In order to solve the above-mentioned existing problems, the present utility model provides a lifting component that is convenient to drive the reception touch screen to rise and fall, and is convenient for people with different heights to use the reception touch screen, and the adjustment component is convenient to drive the reception touch screen to change the angle. It is an intelligent reception robot with high practicability, simple operation, stable structure, reasonable design, convenient use, stability and reliability.

5. The technical scheme adopted by the present utility model is as follows: the present intelligent welcome and reception robot includes a robot base, a robot mobile roller, a robot body, a robot head, a robot face display screen, a support plate, a reception touch screen, a lift assembly, lifting support rod and adjustment assembly, the robot moving rollers are symmetrically arranged at both ends of the bottom wall of the robot base and are rotatably arranged below the robot base, the robot body is arranged above the robot base, and the robot head is arranged on the robot Above the body, the robot face display screen is arranged on the side wall of the robot head, the support plate is slidably arranged on one side of the robot body, the reception touch screen is arranged above the support plate, and one end of the reception touch screen is arranged It is hinged with the top wall of the support plate. The lifting assembly is arranged in one end of the robot body and symmetrically under the two ends of the supporting plate. The lifting assembly includes a lifting chute, a lifting slider, a lifting screw, a lifting motor, and a guide slide. slot, guide slider and guide slider, the lift slot is arranged on the side wall of the lower end of the robot body, the lift slider is slidably arranged in the lift slot, the lift screw is rotatably arranged in the lift slot and Passing through the lifting slider, the lifting motor is rotatably arranged on one side of the lifting chute and is connected with the lifting screw. The guiding chute is arranged on the side wall of the robot body and above the lifting chute. The end of the support plate close to the robot body is slidably arranged in the guide chute, the guide slide bar is arranged in the guide chute and passes through the guide slider, the lift support bar is arranged under the support plate, and the lift support One end of the rod is connected with the lifting slider, the end of the lifting support rod away from the lifting slider is hinged with the end of the support plate away from the robot body, and the adjustment component is arranged on the side of the support plate close to the reception touch screen. The assembly includes an adjustment chute, an adjustment slider, an adjustment screw, an adjustment motor and an adjustment support rod. The adjustment chute is arranged on the top wall of one end of the support plate close to the robot body, and the adjustment slider is slidably arranged on the adjustment chute. Inside, the adjustment screw is rotatably arranged in the adjustment chute and passes through the adjustment slider, the adjustment motor is rotated and arranged on one side of the adjustment chute and is connected with the adjustment screw, and the adjustment support rod is arranged on the reception touch screen Between the adjusting support rod and the support plate, the two ends of the adjusting support rod are respectively hinged with the adjusting slider and the reception touch screen.

6. Further, the upper end of the reception touch screen is provided with a face recognition camera, and the face recognition camera is convenient for identifying guest information.

7. Further, a sundries storage hook is provided on one side of the upper end of the robot body, and the sundries storage hook is convenient for storing the guests' carry-on sundries.

8. Further, a garbage storage box is provided on the side of the robot body away from the sundries storage hook. The garbage storage box is arranged in a hollow cavity with an upper end open, and the garbage storage box is convenient for collecting guests' garbage.

9. Further, a lithium battery is provided in the body of the robot, and the lithium battery is convenient to provide electric power for the robot.

10. Further, the robot body is provided with a networking device, and the networking device is convenient for the robot to be connected to the network.

11. Further, the robot body is provided with a controller, and the controller is respectively connected with the robot moving wheel, lithium battery, networking device, lifting motor, adjusting motor, reception touch screen, face recognition camera, and robot face. The display screen is electrically connected.

12. The beneficial effects obtained by adopting the above structure are as follows: In this scheme, the intelligent welcome and reception robot, the lifting motor drives the support plate to rise and fall through the lifting screw, thereby driving the reception touch screen above the support plate to rise and fall, which is convenient for different heights. When people use the reception touch screen, the adjustment motor changes the angle of the adjustment support rod by adjusting the screw rod, so that the angle of the reception touch screen changes, which is convenient for viewing and using the reception touch screen, with high practicability, simple operation, stable structure, reasonable design, Easy to use, stable and reliable.
