Adjustable fuser base technology realization elements

Technical realization elements:

3. The main purpose of the present utility model is to provide a freely adjustable fuser base, which can effectively solve the problems in the background art.

4. In order to achieve the above-mentioned purpose, the technical scheme adopted by this utility model is:

5. A freely adjustable fuser base, comprising a seat plate, the upper left rear part and the upper right rear part of the seat plate are respectively fixedly connected with a left support and a right support, the left end of the left support A fixing screw is inserted and movably connected. The right end of the right support is clamped and fixed with a fixing nut. The right part of the fixing screw passes through the left end surface of the right support and is threaded into the fixing nut. The movable socket is connected with a rotating support, the rotating support is movably connected between the left support and the right support, and the upper end of the rotating support is fixedly connected with a fuser handle socket.

6. Preferably, the left end front part and the right end front part of the fuser handle socket are both set in inwardly inclined slopes, and the upper end of the fuser handle socket is provided with a slot No. 1, the slot No. 1 A second slot is opened on the lower inner wall surface of the fuser, a through slot is opened on the front end of the fuser handle socket, and the through slot is communicated with the first slot.

7. Preferably, the upper left end of the left support is provided with a T-shaped hole for installing a fixing screw, and the upper right end of the right support is provided with a hexagonal groove for installing a fixing nut.

8. Preferably, the fuser handle socket and the rotating support are both made of polyurethane plastic and are made in one piece.

9. Preferably, the seat plate, the left support and the right support are all made of polyurethane plastic and are made in one piece.

10. Preferably, the lower end surface of the second slot extends into the rotating support.

11. Compared with the prior art, the utility model has the following beneficial effects:

12. In this utility model, the left support, the right support, the fixed screw, the fixed nut and the rotating support are arranged. The rotating support is connected to the left support and the right support through the fixed screw and the fixed nut, and the rotating support can Flip relative to the seat plate, so that the fuser handle socket can also be flipped relative to the seat plate. When in use, the fuser handle can be flipped to change the use height of the fuser. The fuser can be at an angle of 135°-45° The positioning between the operator does not require the operator to bend over or lower the head, and is convenient to use. When carrying, the fuser handle socket and the seat plate can be folded together, which is convenient to carry.
