Technical Realization Elements Of Leisure Dining Chair Processing Device

Technical implementation elements:

3. The purpose of the present utility model is to propose a leisure dining chair processing device in order to solve the problems existing in the above-mentioned background technology.

4. in order to achieve the above object, the utility model has adopted the following technical solutions:

5. A leisure dining chair processing device, comprising a workbench, a through box, a support rod, a rail rod, a first electric telescopic rod and a first rectangular collar, and a through box is arranged through the center of the upper surface of the workbench, so The left and right sides of the upper surface of the workbench are fixedly provided with support rods, the upper surface of the support rods is fixedly provided with a track rod, and the left side of the upper surface of the track rod is fixedly provided with a first electric telescopic rod. The left side socket of the rod is provided with a first rectangular collar;

6. The first rectangular collar includes a fixed plate, a second electric telescopic rod, a rotary motor, a drill bit installer and a drill bit;

7. A fixing plate is fixed on the left side of the upper surface of the first rectangular collar, a second electric telescopic rod is fixed on the bottom surface of the first rectangular collar, and the output end of the second electric telescopic rod is fixed A rotary motor is provided, an output end of the rotary motor is fixedly provided with a drill bit mounter, and a drill bit is mounted on the drill bit mounter.

8. Preferably, the output end of the first electric telescopic rod is fixedly arranged on the left side surface of the fixing plate.

9. Preferably, an infrared lamp is fixed on the bottom surface of the drill bit mounter, and the infrared lamp is in the shape of a ring.
