Technical Realization Elements Of A Traditional Chinese Medicine Internal Medicine Diagnosis And Detection Breathing Device

Technical implementation elements:

3. According to the above deficiencies in the prior art, the technical problem to be solved by the present invention is: to provide a traditional Chinese medicine internal medicine diagnosis and detection breathing device, which can be cleaned directly through the breathing device without moving to a special place for cleaning.

4. The described TCM internal medicine diagnosis and detection breathing apparatus includes a box body, which is provided with a breathing detector for monitoring breathing, the breathing detector has a gas inlet, and the box is provided with a communication gas inlet and extends to The exhalation pipe outside the box is connected with a breathing mask for the patient to wear on the mouth and nose; the box is provided with a cleaning component for washing the inside of the breathing mask.

5. Further, the box body is provided with a cleaning tank with a top opening and is used to install a breathing mask and cleaning liquid, and a water outlet for controlling the discharge of cleaning liquid in the cleaning tank is arranged on the box body; At the bottom of the servo motor, the output shaft of the servo motor extends longitudinally into the cleaning tank and is provided with a roller brush for cleaning the inside of the breathing mask, and the output shaft of the servo motor is provided with a fan blade for agitating the cleaning liquid in the cleaning tank.

6. Further, the breathing mask includes a contact end for contacting the patient's face and an exhalation end, the exhalation end is provided with a connecting pipe, and the connecting pipe and the exhalation pipe are detachably connected.

7. Further, a fixing clip for clamping the connecting pipe is arranged in the cleaning tank, and the fixing clip is located directly above the roller brush.
