Shock-resistant Switch Machine Case Technical Implementation Elements

Technical implementation elements:

5. The inventor found through research that the existing switch machine cannot have good seismic performance in daily operation, the seismic effect is poor, and the vibration damage of the internal structure will also occur.

6. The purpose of the present disclosure is to provide a shock-resistant switch machine casing, by connecting and setting a bottom plate, a latex pad, a woven pad and a reinforcing pad layer by layer, to solve the problem that the switch machine in the prior art is used in daily use and affected by vibration. At the same time, the box is vulnerable to wear and the internal operating components will also cause technical problems.

7. According to an aspect of the present disclosure, a shock-resistant switch machine casing is provided, comprising a casing, a bottom surface of the inner bottom end of the casing is fixedly mounted with a bottom plate, and a connection top is sleeved on the upper end surface of the casing. cover;

8. The bottom surface of the bottom plate is fixedly installed with a latex pad, the bottom surface of the latex pad is fixedly mounted with a woven pad, the bottom surface of the woven pad is fixedly mounted with a reinforcing pad, the bottom plate, the latex pad, The woven pad and the reinforcing pad are fixedly connected by an adhesive.

9. In some embodiments of the present disclosure, the material of the bottom plate is set to be rubber, the material of the woven pad is set to be plastic, the material of the reinforcing pad is set to be stainless steel, and the surfaces of the reinforcing pad are located at the edges of both ends. A spacer is installed symmetrically and fixedly, and the surface of the spacer is provided with a butt hole.
