M14 Red Stainless Steel Extension

1 The dimensioning method on the part drawing should be adapted to the characteristics of CNC machining. On the part drawing of CNC machining, the dimensions should be quoted with the same datum or the coordinate dimensions should be given directly. This labeling method is not only convenient for programming, but also facilitates the coordination between dimensions, which brings great convenience in maintaining the consistency of the design reference process reference detection reference and the programming origin setting. Because part designers generally consider assembly and other use characteristics in dimensioning, they have to adopt a locally scattered labeling method. The base point or node coordinates are calculated during manual programming.
