Frisby Metal Collapsible Club Handle

The upper end is slidably connected with the carriage in the upper workbench device through the guide rail, and the two ends of the carriage in the upper workbench device are hinged with the driving screw rods provided on the front bracket and the rear bracket, and are driven by the driving screw rod to make the upper work The table device slides along the X-axis direction, the fixed column is fixedly connected with the base, the movable column is connected with the base through the driving screw fixed on the base, and driven by the driving screw, so that the movable column travels along the X-axis direction of the driving screw , There is a horizontal spindle box on the movable column, and the horizontal spindle box is slidably connected to the movable column through the vertical drive screw fixed on the movable column, and is driven by the vertical drive screw to slide along the Y-axis direction. There is a vertical spindle box. The vertical spindle box is slidably connected to the fixed column through the vertical drive screw fixed on the fixed column, and is driven by the vertical drive screw to slide in the Y-axis direction. Vertical machining center machine tools and horizontal machining centers The machine tool is integrated into one body, sharing the upper and lower workbenches, which reduces the floor space, reduces the processing assistance, and improves the work efficiency.
