Elements Of Technical Realization Of Parts Clamping Equipment For Mechanical Product Design

Technical implementation elements:

4. In view of the above technical problems, the present invention discloses a part clamping device for mechanical product design, which includes a support device, and a clamping device and an execution trigger mechanism are installed on the support device; the clamping device includes a lifting frame, which is installed on the lifting frame. There are two groups of clamping mechanisms. The two groups of clamping mechanisms are divided into a first clamping mechanism and a second clamping mechanism. The first clamping mechanism and the second clamping mechanism are provided with two, which are symmetrically installed on the lifting frame. , both the first clamping mechanism and the second clamping mechanism are installed with a thin rod, the top of each thin rod is matched with the execution trigger mechanism, and the tops of the four thin rods contact each other to form a closed square, which is suitable for all the thin rods. The first clamping mechanism and the second clamping mechanism are respectively installed on one end of the four connecting rods, the other end of each connecting rod is rotatably connected with the driven gear, and the driven gear meshes with the driving gear , the driving gear is fixedly installed on the output end of the motor 1. When the first clamping mechanism and the second clamping mechanism move the contact material, they will drive the inner extrusion block to move the driving thin rod away from the execution trigger mechanism, forming a four-end opening square, release the restriction on the execution trigger mechanism.

5. Further, the first clamping mechanism includes a clamping frame 1, the bottom of the clamping frame 1 is slidably installed on one end of the connecting rod, the middle clamping frame 1 is slidably installed on the lifting frame, and the clamping frame 1 is slidably installed on the lifting frame. A friction clip is fixedly installed on the friction clip, an extrusion block is slidably installed on the friction clip, one end of the spring one is fixedly installed on the extrusion block, the other end of the spring one is fixedly installed on the clamping frame 1, and the clamping frame 1 is fixedly installed There is a bracket, one end of a plurality of springs 3 is fixedly installed on the bracket, the other end of the springs 3 is fixedly connected with the second toggle lever, the top of the toggle lever two is in contact with the execution trigger mechanism, and one side of the clamping frame is on both sides. The side clips are slidably installed, one end of the second spring is fixedly installed on each side clip, and the other end of the second spring is fixedly installed on the first clamping frame.
