Elements Of Technical Realization Of Fixed Structures For Fast Positioning Of Wood-plastic Panels

Technical implementation elements:

3. The main purpose of the present invention is to provide a fast-positioning fixing structure for wood-plastic board production, which can effectively solve the problems mentioned in the background art.

4. for realizing the above-mentioned purpose, the technical scheme that the utility model takes is:

5. A fast-positioning fixed structure for production of wood-plastic panels, comprising a movable chute and a positioning base, an installation gap is opened in the middle of the positioning base, and a drive mechanism is provided at the installation gap in the positioning base, and the The drive mechanism includes a No. 1 pulley, a drive shaft, a bearing, a transmission belt, a No. 2 pulley and a servo motor. The drive shaft
