Elements Of Technical Realization Of Endoscopic Devices

Technical implementation elements:

4. The purpose of the present invention is to provide an endoscope device that increases the service life of the capsule endoscope.

5. In order to achieve one of the purposes of the above utility model, an embodiment of the present utility model provides an endoscope device, comprising a capsule endoscope and a traction component connected to the capsule endoscope, the traction component comprising an adsorption capsule. The sleeve of the endoscope, the capsule endoscope includes a rear shell matched with the sleeve, a front shell connected to the rear shell and at least partially exposed to the outside of the sleeve, the capsule endoscope is sealed and provided with a transparent A light film, the light transmission film covers at least the outer surface of the front case.

6. As a further improvement of an embodiment of the present invention, a detection layer is provided between the capsule endoscope and the light-transmitting film.

7. As a further improvement of an embodiment of the present invention, the light-transmitting film is covered on the outer surfaces of the front case and the rear case, and the detection layer is arranged on the outer surfaces of the front case and/or the rear case.

8. As a further improvement of an embodiment of the present invention, the capsule endoscope further comprises a
