What are the requirements for the installation foundation of CNC machining center?

1. The installation foundation must be stable to avoid settlement.



Reasons for analysis: If the concrete structure is thick enough for the relatively tight ground, you can directly carry out the construction of the anchor bolts; for the loose foundation, you must re-excavate the area where the equipment is installed and apply a sufficient thickness. Concrete to prevent equipment settlement in the later stage.

2. The size of the foundation should be large enough, and the thickness of the concrete should be thick enough.

Reasons for analysis: Heavy and precision machining center machine tools should be installed with separate foundations, and the foundation size should not be less than the outer dimension of the machine tool support area, and should meet the size required for installation, adjustment, and maintenance; the foundation concrete construction thickness should conform to the country standard.

3. Precision machine CNC machining center machine tool should be equipped with vibration isolation groove

Reason for analysis: The processing accuracy of the precision machining center is greatly affected by vibration, especially when there are relatively large vibration sources (such as punches) around, the vibration isolation groove can effectively weaken its impact. The depth of the vibration isolation groove should be the same as the base depth, and the width is generally 10 cm. The vibration isolation groove is filled with sponge, latex and other materials.

4. The foundation of the heavy machine tool should be isolated from the support of the plant column

Reason for analysis: Due to the heavy weight of the heavy machine tool and the heavy weight of the processed parts, the impact on the foundation is greater. If it is connected to the column support of the plant or is too close, it may have a certain impact on the support of the plant column, which may lead to unpredictable safety Hidden dangers.

What are the consequences of not laying foundations for CNC machining centers?

It is recommended that each machining center should be grounded. Some factories bought the machining center without foundation, and finally used a lot of problems. Useful, sometimes a heavy cut will go down.
