What are the advantages of horizontal CNC machining centers? How to install a horizontal CNC machining center?

Horizontal CNC machining center compared with vertical machining center, horizontal machining center for workpiece processing is easier to chip, for complex concave and die cavity processing is more advantageous, because of the advantages of horizontal machining center structure, can process large workpiece.

The X, Y and Z coordinate screw of the horizontal CNC machining center adopts advanced hollow cooling technology, which effectively controls the heating and deformation of the machine tool in the process of machining motion, and improves the machining accuracy of the CNC machine tool: In addition, the CNC machine tool has the temperature compensation function, the main position of the body is equipped with temperature sensing elements, through the CNC system analysis and compensation coordinates of the position to achieve high precision machine tool. The positioning accuracy of machine tool Y and Z axis can reach ±0.0025mm, the positioning accuracy of cover axis can reach ±0.003mm, and the repeatable positioning accuracy of y and Z axis can reach ±0.002mm.

Horizontal CNC machining center should be installed far away from the source, do not be direct sunlight, no heat radiation and no moisture. If there is a source near the installation of the horizontal machining center, the seismic trench should be set around the horizontal machining center. If not set shockproof groove will directly affect the machining accuracy and stability of the horizontal machining center, a long time will affect the electronic components of bad contact, failure, affect the reliability of the horizontal machining center.

Temperature and humidity can directly affect the horizontal machining center

CNC machining center generally to be in an environment of less than 30 degrees Celsius to work normally, under normal circumstances horizontal machining center distribution box are equipped with exhaust fan and air cooler, to ensure that electronic parts and central processing in a constant temperature state of work. If the temperature and humidity is too high, it will lead to a reduction in the life of the components of the control system, resulting in an unreasonable increase in the failure of the horizontal machining center. If the humidity increases, dust will increase on the integrated circuit board directly resulting in poor contact and short circuit fault.

Voltage and current are strictly controlled

Horizontal CNC machining centers are generally installed in the processing workshop, and the processing workshop of a large number of mechanical equipment, it is inevitable that the power grid fluctuations. So the position of the horizontal machining center installation must strictly control the voltage and current of the power supply, the voltage and current of the power supply must be controlled in the permissible range of the horizontal machining center, must keep the voltage and current of the power supply stable, otherwise it will directly affect the normal work of the horizontal machining center.
