The technical realization elements of the medical material delivery robot with disinfection cabinet

Technical implementation elements:

4. The purpose of this utility model is to provide a medical material transport robot with a sterilization cabinet to solve the problems raised in the above-mentioned background technology.

5. In order to achieve the above purpose, the utility model provides the following technical solutions: a medical material transport robot with a sterilization cabinet, comprising a base, on which four motor wheels are arranged, and a box body is fixedly installed on the top of the base , the outer surface of the box body is provided with an opening, a first motor is installed on the top of the box body, the output end of the first motor extends to the inside of the box body, and the inside of the box body is movably installed with a rotating casing, the outer surface of the rotating casing is provided with an opening, the output end of the first motor is fixedly connected with the top of the rotating casing, the bottom wall inside the rotating casing is fixedly installed with a first fixing rod, the Two support plates are fixedly installed on the first fixing rod, iron nets are fixedly installed on the tops of the two support plates, and a fixed sleeve is fixedly installed on the top of the inner side of the rotating shell, and the inside of the fixed sleeve is fixedly installed with The second motor, the output end of the second motor extends to the bottom of the fixed sleeve, the output end of the second motor is fixedly installed with a rotating plate, and the bottom of the rotating plate is fixedly installed with two second fixing rods , UV germicidal lamps are fixedly installed on the two second fixing rods, and drying equipment is fixedly installed on the left side of the box body.

6. Preferably, two fixing plates are fixedly installed on the top of the base, and two material boxes are fixedly installed between the two fixing plates.

7. Preferably, a push rod is fixedly installed between the two fixing plates.

8. Preferably, the drying device includes a fixing frame, and two fans are fixedly installed inside the fixing frame.

9. Preferably, the outer surface of the rotating casing is provided with a plurality of ventilation holes.

10. Preferably, a heating net is fixedly installed inside the fixing frame.

11. Compared with the prior art, the beneficial effects of the present utility model are as follows: the utility model has a scientific and reasonable structure, is safe and convenient to use, and starts the first motor during use, and the first motor drives the rotating casing to rotate, thereby opening the device, Then take the medical appliance on the support plate, place the medical appliance on the support plate after use, and control the first motor to turn off the device, then start the ultraviolet germicidal lamp, and by starting the second motor, the second motor drives The rotating plate rotates, thereby

Drive the ultraviolet germicidal lamp to rotate, and then sterilize the medical appliances in an all-round way, and by starting the drying equipment, the medical appliances can be dried, and by starting the heating net and the fan, the fan blows out hot air, and then achieves drying. Effect. The utility model has the effect of disinfection and drying by setting a series of structures.
