The technical realization elements of the heat sink of electrolytic copper foil

Technical realization elements:

5. In view of this, the present utility model provides a device that can not only have a certain heat dissipation during the use of the electrolytic copper foil, but also have a certain dust removal during the use.

6. In order to solve the above technical problems, the present utility model provides a heat dissipation device for electrolytic copper foil, which includes a support frame, an electrolytic copper foil body, and a heat dissipation mechanism. The fixed pile is provided with a rotating mechanism, the electrolytic copper foil body is rotatably connected to the fixed pile, and the heat dissipation mechanism includes a bracket frame corresponding to the electrolytic copper foil body on a supporting frame, and a mounting frame is provided on the bracket frame. A fan body is arranged on the frame, an arc-shaped fixing frame is arranged on the support frame corresponding to the electrolytic copper foil body, a first filter is arranged on the arc-shaped fixing frame, and a second filter is arranged on the lower end of the bracket frame corresponding to the fan body An auxiliary mechanism is provided on one side of the support frame corresponding to the end of the electrolytic copper foil body.

7. Further, the auxiliary mechanism includes support rods provided on both ends of one side of the support frame corresponding to the electrolytic copper foil body, the support rod is provided with a rotating shaft, the rotating shaft is provided with a communicating shaft, and The inside is a cavity, the cooling liquid is arranged in the cavity, the communication shaft is placed in the cavity and is connected to the rotating shaft in a rotationally closed connection, and a micro compressor is arranged at the lower end of the support frame, and the micro compressor includes a capillary tube The capillary tube is placed in the cavity through the communicating shaft and communicates with the micro compressor.

8. Further, the rotating shaft is attached to the end of the electrolytic copper foil body, and a placement frame is provided on the support frame corresponding to where the electrolytic copper foil body and the rotating shaft are attached, and an ion rod is provided on the placing frame.

9. Further, the fan body is connected to a power supply line.

10. Further, the micro compressor is connected to a power supply line.

11. The beneficial effects of the above technical scheme of the present utility model are as follows:

12. The fixed pile is arranged at the upper end of the support frame, and the fixed pile is connected with the electrolytic copper foil body by rotation, so that the electrolytic copper foil

The body has a certain degree of stable rotation. Through the bracket frame set on the support frame, the mounting frame set on the bracket frame, the fan body is set on the mounting frame, and the end of the fan body corresponding to the electrolytic copper foil body is fixed on the mounting frame, thereby The heat at the end of the electrolytic copper foil body is effectively dissipated under the action of the fan body, and the arc fixing frame provided on the supporting frame corresponding to the electrolytic copper foil body, and the first filter set on the arc fixing frame, pass through When the fan body makes the air flow into and out of the end of the electrolytic copper foil body, the impurities in the airflow are effectively removed, thereby improving the cleanliness of the end of the electrolytic copper foil body. The filter screen prevents impurities in the air from entering the airflow and entering and exiting the end of the electrolytic copper foil body, thereby improving the heat dissipation of the electrolytic copper foil body.
