The technical realization elements of the environmentally friendly operation platform for high-safety testing

Technical realization elements:

5. In order to allow workers to safely operate above the console, this technology provides a high-safety environmentally friendly console for testing.

6. This technology provides a high-safety environmental protection console for testing, using the following technical solutions:

7. A high-safety environment-friendly operating platform for testing, including a storage cabinet and an operating room. The operating room is located above the storage cabinet and connected to the storage cabinet. The operating room is a hollow box with a side wall of the operating room. It is a front window. The front window includes a fixed plate and a sliding plate. The sliding plate is located below the fixed plate and is slidably connected with the sliding plate. The sliding plate and the fixed plate can cooperate to close the operating room. The top wall of the operating room is connected with an exhaust pipe. An end of the exhaust pipe away from the operating room is provided with a suction fan, and the sliding plate near the bottom end is provided with an operating port for passing the worker's arm. The operating port is covered with a cover plate, and the cover plate is hinged with the sliding plate.

8. By adopting the above technical scheme, when the staff does not need to operate, close the cover plate and pull down the sliding plate to the front window to close the entire operation room. At this time, the harmful gas in the operation room is discharged by the suction fan. It is helpful to the health of the staff; when the staff needs to operate, they can first open the cover and extend the arm into the operating room through the operating port. At this time, there is no need to move the sliding plate, which helps to reduce the amount of work in the operating room. Possibility of harmful gases to diffuse to the outside world, improving the safety of the console.

9. Optionally, a first fixing member for covering the cover plate is provided between the cover plate and the sliding plate, and the first fixing member includes

A connecting rod and a connecting block. The connecting rod includes a first vertical part, a horizontal part and a second vertical part. The first vertical part is rotatably connected with the sliding plate, and the bottom wall of the second vertical part is provided with a clamping block for accommodating One end of the horizontal part is fixedly connected to the first vertical part, and the other end is fixedly connected to the second vertical part.

10. By adopting the above technical solution, when the cover plate is closed, the first vertical part is rotated to make the connecting block enter the slot. At this time, the cover plate can better close the operation port and make the harmful gas in the operation room It is not easy to spread from the operating port to the outside world, thereby improving the safety of the operating table.

11. Optionally, a sealing gasket is fixedly connected to the side of the cover plate close to the sliding plate.

12. By adopting the above technical solution, when the cover plate is covered, the gasket helps to make the cover plate and the sliding plate fit, thereby helping to prevent harmful gases in the operating room from passing through the gap between the cover plate and the sliding plate. Spread to the outside world.

13. Optionally, a second fixing part for making the cover difficult to cover is provided between the cover plate and the sliding plate. The second fixing part includes a hook and a hanging ring. One end of the hook is connected to the fixing plate, and the other end is connected to the hanging ring. The ring can be detachably connected, and the hanging ring is fixedly connected with the cover plate.

14. By adopting the above technical solution, the staff holds the hook to rotate the cover, and then hooks the hook to the hanging ring. At this time, the cover can be fixed for a long time, so that the operation port is not blocked, and it is convenient for the staff’s arm to move smoothly at the operation port. Reach in or out to facilitate the operation of the staff.

15. Optionally, the hook includes a connecting rope and a hook, one end of the connecting rope is fixedly connected with the fixing plate, the other end is fixedly connected with the hook, and the hook is fixedly connected with the hanging ring.

16. By adopting the above technical solution, the connecting rope is light in weight, and it is not easy to damage the sliding plate or the fixed plate when it comes into contact with the sliding plate or the fixed plate.

17. Optionally, a protective cover is provided at the operating port. The protective cover is located inside the operating room. The protective cover is fixedly connected to the inner wall of the sliding plate and communicates with the operating port. The diameter of the protective cover gradually decreases in the direction away from the sliding plate. .

18. By adopting the above technical solution, the worker's arm extends into the protective cover. The protective cover can protect the worker's arm and help reduce the possibility of the toxic gas in the operating room diffusing to the outside world.

19. Optionally, the operation ports are set to two with the same structure.

20. By adopting the above technical scheme, the staff’s arms are respectively extended into the two operating ports for operation, which helps to improve the applicability of the operating port and the human arm, reduce the gap between the staff’s arm and the operating port, and reduce The possibility of harmful gases in the operating room diffuse to the outside world further improves the safety of the operating table.

21. Optional, the operation port is round.

22. By adopting the above technical solution, the applicability of the operation port and the human arm is improved, which helps to reduce the gap between the worker's arm and the operation port, and reduces the possibility of the harmful gas in the operation room diffusing to the outside world.

23. To sum up, this technology includes at least one of the following beneficial technical effects of high-safety environmentally friendly operation consoles for testing:

24.1. By opening the operating port on the sliding panel, after the front window is closed, the staff's arms can still be extended into the operating room for experimental operations. At this time, it helps to reduce the possibility of harmful gases in the operating room from spreading to the outside world. Performance, which helps to improve the safety of the console;

25.2. By setting up a protective cover at the operation port, it can protect the staff's arms and reduce the possibility of harmful gases spreading to the outside world;

26.3. By fixing and connecting the gasket on the inner wall of the cover plate, the gas in the operating room can not easily diffuse from the gap between the cover plate and the sliding plate to the outside, which improves the safety of the operating table.
