The technical realization elements of the cutting structure of the corrugated paper slitting machine

Technical implementation elements:

4. The utility model provides a corrugated paper slitting machine cutting structure, which aims to solve the problem that when the existing slitting machine cuts the corrugated paper, it is usually manually placed one by one, and the labor will be consumed for a long time. , when the user is tired, the production efficiency will be reduced, and the slitting machine will produce chips during processing, which usually fall directly on the ground, which is inconvenient for cleaning and increases the difficulty of the user's operation.

5. The utility model is realized in this way, a corrugated paper slitting machine cutting structure includes a slitting machine main body, the front side of the slitting machine main body is movably connected with an operating table, and the inner cavity of the operating table is provided with a lift. mechanism, the top of the operating table is provided with a transmission mechanism that cooperates with the lifting mechanism;

6. The lifting mechanism includes a placement slot, the inner cavity of the placement slot is movably connected with a placement plate, the side of the placement plate close to the inner wall of the placement slot is in contact with the inner wall of the placement slot, and the bottom of the placement plate is fixedly connected with a placement plate. A first electric telescopic rod, the bottom of the first electric telescopic rod is fixedly connected with the inner wall of the placing slot.

7. In order to achieve the effect of transmitting the corrugated paper, it is preferable as a corrugated paper slitting machine cutting structure of the present utility model, the transmission mechanism includes two moving blocks, and the opposite sides of the two moving blocks are movably connected. A rotating shaft, a motor is fixedly connected to the left side of the moving block on the left side, and an output end of the motor is fixedly connected to the rotating shaft.

8. In order to achieve the effect of collecting waste chips, as a corrugated paper slitting machine cutting structure of the present utility model is preferable, the left side of the slitting machine main body is movably connected with a storage box, and the The left side is provided with a groove for use with the storage box.

9. In order to achieve the effect of preventing the offset of the storage box, as a corrugated paper slitting machine cutting structure of the present invention, it is preferable that the front side and the rear side of the storage box are fixedly connected with sliding rods, and the grooves are The inner cavity is provided with a chute which is used in conjunction with the sliding rod.

10. In order to achieve the effect of pushing the corrugated board, as a corrugated paper slitting machine cutting structure of the present invention, it is preferable that the inner cavity of the placing slot is movably connected with a push plate used in conjunction with the placing plate, and the push plate is The front side of the board is fixedly connected with a second electric telescopic rod.

11. In order to achieve the effect of partitioning the corrugated board, it is preferable as a corrugated paper slitting machine cutting structure of the present utility model, the left side of the operating table is movably connected with an l-shaped board used in conjunction with the push plate, so the The left side of the operating table is movably connected with a baffle.

12. In order to achieve the effect of facilitating the pulling of the baffle, as a corrugated paper slitting machine cutting structure of the present invention, it is preferable that the top of the operating table is fixedly connected with two guide blocks, and the left side of the baffle is Active connections have handles.

13. Compared with the prior art, the beneficial effects of the present utility model are:

14. The cutting structure of the corrugated paper slitting machine, by setting the lifting mechanism, the user places a plurality of corrugated paper on the top of the placing board. After the placement is completed, the main body of the slitting machine and the first electric telescopic rod and the first electric telescopic rod are activated at the same time. Drive the placement board to move upward, the placement board drives the corrugated paper to move upward, when the corrugated paper moves to a certain position, the first electric telescopic rod stops running, and the corrugated paper is moved through the transmission mechanism, so that the main body of the slitting machine cuts the corrugated paper. , the first electric telescopic rod starts again to drive the placing plate to move upward, so as to achieve the effect of automatic feeding, and it is not necessary to manually place one by one, thereby reducing the labor force.
