The technical realization elements of the control system of the high-end flexible edge banding machine

Technical implementation elements:

3. The purpose of the present invention is to provide a control system for a high-end flexible edge banding machine, which controls different mechanisms through servo drives, so as to achieve resource optimization, improve processing accuracy, and solve edge banding of different sizes and thicknesses. Difficult to adjust and poor sealing effect.

4. the present invention is achieved through the following technical solutions:

5. A control system for a high-end flexible edge banding machine, comprising a motion controller and a man-machine dialogue unit; the motion controller is connected in communication with the man-machine dialogue unit; the motion controller is respectively connected with a host computer in communication pc unit, pressure beam control unit, spraying control unit, pre-milling cutter control unit, gluing control unit, 12-bit tape change control unit, servo pressing control unit, front and rear servo control unit, rough trimming control unit, fine trimming Control Unit, Tracking Profile Control Unit, Scraping Servo Control Unit, Flat Scraping Control Unit, Polishing Control Unit, Cleaning Control Unit, Horizontal Grooving Servo Control Unit and Vertical Grooving Servo Control Unit.

6. Further, the control system of the high-end flexible edge banding machine also includes a pressing beam mechanism, a spraying mechanism, a pre-milling tool mechanism, a gluing mechanism, a 12-position belt changing mechanism, a servo pressing mechanism that are electrically connected to the motion controller respectively. Sticking mechanism, front and rear flush servo mechanism, rough trimming mechanism, fine trimming mechanism, tracking profiling mechanism, scraping servo mechanism, flat scraping mechanism, polishing mechanism, cleaning mechanism, horizontal slotting servomechanism and vertical slotting servomechanism; The PC unit of the upper computer controls the press beam mechanism, the spraying mechanism, the pre-milling mechanism, the gluing mechanism, the 12-bit belt changing mechanism, the servo pressing mechanism, the front and rear aligning servo mechanism, and the rough repair mechanism respectively through the motion controller. , Refining mechanism, tracking profiling mechanism, scraping servo mechanism, flat scraping mechanism, polishing mechanism, cleaning mechanism, horizontal slotting servo mechanism and vertical slotting servo mechanism.
