The technical realization elements of the button processing equipment with the heat dissipation function of the collection cassette

Technical realization elements:

3. In order to make up for the above shortcomings, this utility model provides a button processing equipment with a heat dissipation function for the collection cassette.

4. The technical scheme of the utility model is:

5. A button processing equipment with a heat dissipation function for a collection box, comprising a transport box, a collection box is provided at the discharge port of the transport box, the collection box includes a collection box body, and two collection box bodies A side opening is provided with a heat dissipation hole, and a heat dissipation device is fixedly connected to the heat dissipation hole. The heat dissipation device includes an outer cover fixedly connected to the outside of the collection box body, and a connecting plate is fixedly connected to the outer cover, and the connecting plate A second motor is fixedly connected, the output shaft of the second motor is keyed with a transmission shaft rotatably connected with the connecting plate, and a plurality of fan blades are fixed on the outer circumferential wall of the transmission shaft.

6. As a preferred technical solution, a feeding funnel is fixed at the feed opening of the material transport box, and a conveying device is provided in the material transport box.

7. As a preferred technical solution, the conveying device includes several conveyor belts arranged in parallel, both ends of the conveyor belt are rotatably connected with a rotating shaft, the rotating shaft is rotatably connected with the shipping box, and the outer wall of the shipping box is fixed. A number of first motors are connected, one of the rotating shafts on each of the conveyor belts is keyed to the output shaft of the first motor; the conveying box is connected with a blower, and the bottom of the conveying box is fixedly connected with a supply The fixed plate to which the blower is fixed.

8. As a preferred technical solution, the lowermost conveyor belt is provided with a discharge shovel at one end of the discharge opening, and the discharge shovel extends to the outside of the transport box.

9. As a preferred technical solution, a plurality of sieve plates whose apertures gradually decrease from top to bottom are arranged in the body of the collection box, and a baffle with fine holes is fixed on the heat dissipation hole.

10. As a preferred technical solution, a plurality of ventilation holes are provided on the conveyor belt.

11. As a preferred technical solution, supporting legs are fixedly connected to the bottom of the transport box near the four corners.

12. Compared with the prior art, the beneficial effects of this utility model are:

13.1. According to the present invention, a collection box is arranged at the discharge port of the material transport box, and a heat dissipation device is arranged on the collection box. The second motor drives the rotation of the fan blades, which can re-heat the buttons in the collection box and avoid buttons. Deformation and other problems occur at a high temperature for a long time, which affects the quality of the button and can reduce the defective rate of the button.

14.2 The utility model is equipped with a blower, through which the buttons on the conveyor belt can be initially dissipated.

15.3. The utility model is provided with a sieve plate whose aperture gradually decreases from top to bottom, so that the buttons entering the collection box can be initially screened according to their size.
