The technical realization elements of the bolt tightening operation device without power failure

Technical implementation elements:

4. The technical problem to be solved by this utility model is the defect or deficiency existing in the above-mentioned prior art, and a remote-controlled intelligent non-power-off bolt tightening operation device is provided to meet the strict requirements of large-scale bolt tightening in the power industry, while avoiding Safety problems that may be brought about by the direct operation of the operator.

5. in order to achieve the above object, the technical scheme adopted by the present utility model is as follows:

6. An uninterrupted bolt tightening operation device, comprising a bolt tightener, a wireless remote control, an insulating operating rod rod, and a lithium battery, the bolt tightening device and the wireless controller are connected through a wireless network, and a sleeve head is installed on the top of the insulating operating rod The socket head is connected with the rear end of the bolt fastener through the adjusting bolt, the socket head is provided with a ground wire, the bottom of the bolt fastener is integrally provided with a first clamping part, and the lithium battery is clamped and connected with the first clamping part.

7. Further, in some preferred embodiments of the present invention, a motor, a first wireless communication module, an adc sampling module, a first microprocessor, a torque sensor, a first microprocessor, and a first microprocessor are provided inside the bolt fastener. The device is respectively electrically connected with the motor, the first wireless communication module, the ADC sampling module, the torque sensor and the lithium battery.

8. Further, in some preferred embodiments of the present invention, an indicator light is embedded in the rear end of the bolt fastener, and the indicator light is electrically connected to the first microprocessor.

9. Further, in some preferred embodiments of the present invention, the wireless remote control includes a display module, a key module, a power supply module, a second microprocessor, and a second wireless communication module, and the second microprocessor is respectively connected with the The display module, the button module, the power supply module, and the second wireless communication module are electrically connected, and the second wireless communication module is connected with the first wireless communication module through a wireless communication network.

10. Further, in some preferred embodiments of the present invention, the insulating operating rod is at least one, one end of the insulating operating rod is provided with an external thread, the other end is provided with an internal thread, and a plurality of insulating operating rods are detachable through the thread. connect.

11. Further, in some preferred embodiments of the present invention, the rear end of the first clamping portion is provided with a clamping connection.

The front part of the lithium battery is provided with a battery button that matches the clamping block, the middle of the battery button is provided with a chute, the middle of the chute is provided with a long hole, the outer side of the chute is provided with a sliding switch, and the inner side of the chute is provided with a sliding switch. There is a horizontal clip connected to the slide switch, vertical slides are arranged at both ends of the battery button, a groove is formed on the front of the clip block to allow the vertical movement of the clip, and one side of the groove on the clip block is provided with the clip. A matching bayonet is provided, and guide rails matching the slideway are provided on both sides of the clamping block.

12. Compared with the prior art, the beneficial technical effect of the present utility model is:

13.1. The non-power-off bolt tightening operation device of the present utility model remotely controls and monitors the working condition of the bolt tightener through a wireless remote controller, so as to meet the strict requirements of large bolt tightening in the power industry, and at the same time avoid the direct operation of the operator which may bring about It is applied to the fastening of high-voltage live bolts in power transmission and transformation to improve the work efficiency of condition-based maintenance in the work area, eliminate hidden dangers of heat and other faults caused by loosening, and ensure the safety of the power grid.

14.2. The non-power-off bolt tightening operation device of the present invention can be assembled into a tool suitable for the operator according to the on-site use conditions, and has a simple structure, which is an efficient tool for realizing electrified disassembly and assembly of various bolts.
