The realization elements of work frame technology for polishing tungsten tongs pot
Oct 31, 2014
Leave a message
Technical realization elements:
4. For this reason, the embodiment of the present utility model provides a work frame for polishing tungsten tongs pot to solve the problem that the work frame needs to be manually moved from a low place to a high place one by one due to the high position of the work frame in the prior art, and then from the high place. The tungsten tongs pot cannot be adjusted in height due to transportation to the designated polishing position. This is not only time-consuming and labor-intensive, but also easy to cause the operator's waist to sprain, which is more time-consuming and labor-intensive, and the problem of poor practicability.
5. In order to achieve the above purpose, the embodiments of the present invention provide the following technical solutions: a work frame for polishing tungsten tongs pot, including a support plate, the top of the support plate is symmetrically provided with a support frame, one of the two support frames There is a transmission mechanism between;
6. The transmission mechanism includes a driven roller, a first transmission rod is provided inside the driven roller, a first transmission collar is provided at one end of the first transmission rod, and the bottom of the first transmission collar is provided There is a second transmission shaft ring, the second transmission shaft ring is provided with a transmission toothed belt, one end of the second transmission shaft ring is provided with a second transmission rod, and the outside of the second transmission rod is provided with a driving roller, the A transmission connecting belt is arranged outside the driving roller. A plurality of fixed blocks are symmetrically arranged from top to bottom on both sides of the transmission connecting belt. A second arc-shaped cover plate is arranged at the bottom end of the shaped cover plate, a rotating rod is arranged at the other end of the second transmission collar, and a servo motor is installed at one end of the rotating rod.
7. Further, a stable bracket is connected to the bottom end of the servo motor, and the stable bracket is fixedly connected to the servo motor.
8. Further, the bottom end of the support plate is provided with four universal wheels, and the universal wheels and the support plate are welded and fixed.
9. Further, a pull handle is provided on one side of the support frame, and the pull handle and the support frame are welded and fixed.
10. Further, the first transmission rod is fixedly connected to the driven roller, and two ends of the rotating rod are respectively fixedly connected to the output end of the servo motor and the second transmission collar.
11. Further, the top end of the first arc-shaped cover plate is provided with an adjusting screw rod, and the bottom end of the adjusting screw rod is provided with
There is a rotating cap, the rotating cap and the adjusting screw are fixedly connected, the inner walls of the first arc-shaped cover plate and the second arc-shaped cover plate are both provided with a plurality of friction teeth, and the first arc-shaped cover plate is one A protective frame is provided on the side.
12. Further, the friction teeth and the second arc-shaped cover plate are fixedly connected, and the protective frame and the first arc-shaped cover plate are welded and fixed.
13. The embodiments of the utility model have the following advantages:
14.1. By setting a transmission mechanism, the fixed block drives the second arc-shaped cover plate to rotate the first arc-shaped cover plate, so that each first arc-shaped cover plate can be adjusted to an appropriate height through the rotation of the servo motor. Therefore, only the mechanical transmission is needed to adjust to the same height of the polishing table during the transportation, so that the transportation can effectively save the transportation time, the labor of the transportation, and it is more time-saving and labor-saving, convenient and fast, and does not require the operator to bend up and down. Effectively protect the waist, avoid sprains, and carry multiple tungsten tongs pots at the same time, which has higher handling efficiency and better practicability;
15.2. By turning the rotating cap, the rotating cap drives the adjusting screw to rotate, so that the adjusting screw starts to rotate on the first arc cover and the second arc cover, so that the first arc cover and the second arc cover can be adjusted. The distance between the second arc-shaped cover plates makes it convenient to carry tungsten tongs pots of different widths. Multiple friction teeth increase the friction with the tungsten tongs pot so that it is not easy to shake or fall. At the same time, the end of the tungsten tongs pot can be directly It is inserted into the protective frame to play a protective role and has better stability. It is suitable for use with tungsten tongs pots of different widths.
Description of the drawings
16. In order to more clearly explain the embodiments of the present invention or the technical solutions in the prior art, the following will briefly introduce the drawings that need to be used in the description of the embodiments or the prior art. Obviously, the drawings in the following description are only exemplary. For those of ordinary skill in the art, without creative work, other implementation drawings can be derived from the provided drawings.
17. The structure, ratio, size, etc. shown in this manual are only used to match the content disclosed in the manual for people familiar with the technology to understand and read, and are not used to limit the implementation of the present utility model. Therefore, it has no technical significance. Any structural modification, proportional relationship change, or size adjustment should still fall within the scope of the utility model without affecting the effects and objectives that can be achieved by the utility model. The technical content disclosed must be within the scope of coverage.
