The manufacturing method of the barge connecting the fixed channel and the technical realization elements

Technical realization elements:

4. Due to the poor mooring conditions of the current barge in use, it is impossible to accurately fix the barge in the relative position between the protective pile and the wharf, that is, the movement range of the barge is relatively large and cannot be effectively controlled, so we designed a barge Connecting the fixed channel can effectively connect the barge with the protective pile, and can keep the barge's mooring position in the water relatively fixed, with good use effect and convenient for staff to pass.

5. The technical solution of the present utility model to achieve the above-mentioned objects is a barge connecting fixed channel, comprising a turntable installed on the protective pile, a connecting channel, and a universal rotating device installed on the deck of the barge; one end of the turntable is connected to One end of the channel is connected, and the other end of the connection channel is connected with the universal rotating device.

6. As a further supplement to the technical solution, the turntable includes a reinforced bottom plate, a box-shaped structure, and ear plates arranged on both sides of the box-shaped structure; the reinforced bottom plate is welded on the protective pile, and the box-shaped structure is It is provided with through holes penetrating the upper and lower surfaces of the reinforced base plate, and a blind hole is provided at the position corresponding to the through hole on the reinforced bottom plate. On; the ear plate is fixedly installed on the side of the box-shaped structure, one end of the ear plate is hook-shaped, and one end of the reinforced bottom plate is clamped in the ear plate.

7. A further supplement to the technical solution, the longitudinal section of the connecting channel is u-shaped; the four ends of the connecting channel are welded with connecting plates, and the two connecting plates on one side are connected with the lugs through the first rotating shaft, A sleeve is also installed on the first rotating shaft between the ear plate and the connecting plate.

8. As a further supplement to the technical solution, the connecting channel is a truss welded by profile materials.

9. As a further supplement to this technical solution, the universal rotating device includes a box-shaped member, a rotating shaft sleeve arranged below the box-shaped member, and a base arranged below the rotating shaft sleeve; the box-shaped member and the connecting channel are another The two connecting plates on the side are connected by a second rotating shaft that penetrates the box-shaped member, the left and right surfaces of the connecting plate, and one side of the connecting plate is locked by a nut; the upper end of the rotating shaft sleeve is fixed to the box-shaped member Connection; The base is fixedly installed on the deck of the barge.

10. As a further supplement to the technical solution, the box-shaped member includes a rotating box and a third rotating shaft arranged below the rotating box. The rotating box and the connecting plate are connected by a second rotating shaft; the upper end of the third rotating shaft It is fixedly connected with the lower surface of the rotating box, and the lower end of the third rotating shaft is fixedly connected with the inner surface of the rotating shaft sleeve.

11. A further supplement to the technical solution, a fourth rotating shaft is symmetrically welded on both sides of the rotating shaft sleeve, and the bottom

The upper side of the seat is provided with vertical plates on opposite sides, the lower surface of the vertical plate is fixedly connected with the upper surface of the base, and the fourth rotating shaft is installed on the vertical plate and is in sliding contact with the vertical plate.

12. As a further supplement to the technical solution, guard plates are provided on the other two sides above the base, and the two sides of the guard plates are respectively fixedly connected to the vertical plates on both sides, and the lower surface of the guard plate is fixedly connected to the base.

13. The beneficial effect is that the barge can be well moored through the cooperation of the turntable and the universal rotating device, and the barge's berthing position in the water is relatively fixed, and the movement is within a certain range; the setting of the connecting channel can also be used as a means for people to pass through. The working channel is used, the mooring effect is good, and it is safe and reliable.
