Technical realization elements of suction cups and door suction components

Technical realization elements:

3. In order to solve at least one of the above technical problems, the present invention provides a door sucker and a door sucker assembly, and the technical solutions adopted are as follows:

4. The door stopper assembly provided by the present invention includes a door stopper and a door stopper. The door stopper includes a ball end structure, and the ball end structure is used to adsorb to the magnetic attraction part of the door stopper.

5. The door suction cup provided by the present utility model includes a magnetic suction part, a suction cup base, a suction cup shell and a pre-positioning part. The suction cup base is used for installation on a wall or a door. The suction cup base is installed, the magnetic attraction component is arranged in the suction cup housing, the pre-positioning piece is detachably arranged on the suction cup base, and the door suction cup is installed, the pre-positioning piece is used to adhere to On the wall or door.

6. In some embodiments of the present invention, an adhesion structure is provided on the pre-positioning member, and the adhesion structure is used to adhere to the wall or the door.

7. In some embodiments of the present invention, the suction cup base is provided with a base mounting hole, and the suction cup base is installed with a wall or a door through a connector penetrating the base mounting hole.

8. In some embodiments of the present invention, the suction cup housing is installed with the suction cup base through a threaded connection.

9. In some embodiments of the present invention, a positioning hole for installing the pre-positioning component is provided on the suction cup base.

10. In some embodiments of the present invention, the door suction cup includes a packaging component, the packaging component is arranged in the suction cup housing, and the packaging component is configured in the suction cup housing to install the magnetic suction cup. Space for parts.

11. In some embodiments of the present invention, the packaging component is installed with the suction cup housing by means of threaded connection.

12. The embodiment of the present invention has at least the following beneficial effects: first combine the door suction cup and the door suction seat, determine the installation position of the door suction cup through the pre-positioning piece, detach the pre-positioning piece from the door suction cup, and use the pre-positioning piece to move the suction cup base Install on the door or wall, and then install the suction cup shell and the suction cup base, so as to realize the accurate positioning of the door suction cup and the door suction seat, and improve the installation efficiency. The utility model can be widely used in the technical field of home decoration.
