Technical realization elements of multifunctional railway track cleaning and maintenance platform

Technical implementation elements:

7. The purpose of the present invention is to provide a multifunctional railway track cleaning and maintenance platform to solve the related problems raised in the above background art.

8. Technical solutions

9. In order to achieve the above purpose, the present invention provides the following technical solutions: a multifunctional railway track cleaning and maintenance platform, comprising a base, and a first fixing seat is fixedly connected at the middle position of one end of the front face of the top of the base, and the first fixing seat is The inner bearing of the seat is connected with a first transmission shaft, the outer sides of the two sets of the first transmission shafts are provided with worms, the two sides of the first transmission shafts are fixedly connected with a first driven gear, and the front end of the top of the base is provided with a first driven gear. Derusting components are arranged on both sides, walking wheels are arranged at the four corners of the bottom of the base, transmission gears are arranged on the side where the two groups of walking wheels are close to each other, two groups of transmission gears and two groups of first driven gears are arranged. A first chain is sleeved on the outer side of the gear, a second fixed seat is fixedly connected at the middle position of one end of the back of the top of the base, and the inner bearing of the second fixed seat is connected with a second transmission shaft, and the second transmission shaft Incomplete gears are arranged on both sides of the outer side, second driven gears are arranged on both sides of the second transmission shaft, and a second chain is sleeved on the outer sides of the two groups of the transmission gears and the two groups of the second driven gears. A fuel tank is provided on both sides of one end of the back of the top of the base, a telescopic rod is slidably provided on the top of the fuel tank, a float is provided at the bottom of the telescopic rod, and oiling components are provided on both sides of the bottom of the fuel tank.

10. Preferably, the derusting assembly includes a support shaft, a worm gear, a first gear, a grinding roller, a grinding disc, a connecting plate and a second gear, the support shaft is located at the front end of the top of the base, and the top of the support shaft is A worm gear is provided, the bottom of the support shaft penetrates the interior of the base and is provided with a grinding disc, the bottom of the outer side of the support shaft is sequentially provided with a second gear and a connecting plate, and the two sides of the top of the connecting plate are rotated and provided with a first gear. gears, the bottoms of the two sets of first gears are provided with grinding
