Technical Realization Elements of Muffler of Gasoline Generator Set

Technical realization elements:

4. In view of the problems mentioned in the background art, the purpose of the present utility model is to provide a gasoline generator set muffler to solve the problem that the gasoline generator mentioned in the background art is easy to collide with the muffler, causing the muffler to be damaged, and causing damage to the gasoline generator set. Troubleshoot difficult problems.

5. The above-mentioned technical purpose of the utility model is achieved through the following technical solutions:

6. A muffler for a gasoline generator set, comprising a muffler shell, a load-bearing base, a generator mounting frame and a generator body. A load-bearing base is fixedly installed inside the muffler shell, and a generator mounting frame is fixedly mounted on the load-bearing base, and the generator The mounting frame is fixedly arranged on the outside of the generator body, the outside of the generator mounting frame is fixedly installed with a fixed plate, and the outside of the fixed plate is fixedly installed with a shock-absorbing spring device, including a spring buffer seat, a connecting rod, a spring and a fixed block, and the spring buffer The outer side of the seat is fixedly installed with a connecting rod, the outer side of the connecting rod is covered with a spring, the end of the connecting rod away from the spring buffer seat is provided with a fixed block, the fixed block is provided with a fixing groove, and the end of the connecting rod away from the spring buffer seat extends to the fixing groove Inside the muffler shell, there are openings on the front, rear, left and The bottom end is hingedly connected with the inner bottom end of the muffler shell, and an upper cover plate is arranged on the top of the muffler shell.

7. Further, an observation window is opened on the inspection door at the front end of the muffler shell, and glass is fixedly installed in the observation window.

8. Through the above technical solution, the presence of the observation window can facilitate the observation of the gasoline generator set inside the muffler housing.

9. Further, the overhaul doors located on the left and right sides of the muffler shell are fixedly provided with silencer shutters, and exhaust fans are fixedly installed on the silencer shutters.

10. Through the above-mentioned technical solution, by adding noise-absorbing shutters on both sides, the noise-absorbing shutters have the function of ventilation, and the setting of the exhaust fan can exhaust the hot air inside the muffler to the outside of the muffler.

11. Further, a universal wheel is fixedly arranged at the bottom of the muffler shell, and a rubber pad is installed on the outer side of the universal wheel.

12. Through the above technical solution, the universal wheel is provided on the load-bearing base, so that the housing with the muffler is easy to move, and the rubber pad provided on the surface of the universal wheel reduces the noise generated during the movement.

13. Further, a handle is fixedly installed on the outer surface of the inspection door, a door lock is arranged on the outer surface of the inspection door, and a lock catch is arranged on the bottom of the muffler housing corresponding to the door lock.

14. Through the above technical scheme, after the overhaul is completed, use the door lock and lock to fix the overhaul door to prevent the overhaul door from rotating.

15. Further, a handle is provided on the upper cover plate, and the upper cover plate is connected with the muffler shell through a hinge.

16. Through the above technical solution, the upper cover can be opened by the handle when in use, and the user can open the upper cover more labor-saving and convenient.

17. Further, a sealing ring is installed on the inner edge of the access door.

18. Through the above technical scheme, a sealing ring is installed at the edge of the inspection door, which plays a role of sealing.

19. In summary, the utility model mainly has the following beneficial effects: the utility model is fixedly installed with a fixing plate on the outer side of the generator mounting frame, a shock-absorbing spring device is fixedly installed on the outer side of the fixing plate, and the outer side of the spring buffer seat is fixedly installed There is a connecting rod, and the outside of the connecting rod is covered with a spring, which has a buffering effect, which can reduce the shaking generated during the operation of the generator and prevent the gasoline generator from colliding with the muffler; at the same time, the openings on the front, rear, left, and right sides of the muffler shell All hinges have an inspection door, the outer surface of the inspection door is provided with a door lock, and the bottom of the muffler shell is provided with a lock at the position corresponding to the door lock. When the device inside the muffler shell needs to be inspected and repaired, the door lock is opened. The access door can be opened by pulling the handle, which is more convenient.
