Technical realization elements of LED light source color temperature control device

4. The purpose of the present invention is to provide an LED light source color temperature control device to solve the problems raised in the above background technology.

5. The basic scheme of the present utility model is: an LED light source color temperature control device, including a device box, a fixed plate is fixedly installed on both sides of the inner wall of the device box, and a control panel is movably installed on the top of the fixed plate, so the The bottom of the inner wall of the device box is rotatably installed with a heat dissipation assembly, the heat dissipation assembly includes three rotating rods, the tops of the three rotating rods are fixedly installed with fans, and the outer surfaces of the three rotating rods are fixedly installed with driven sprockets , the top of the inner wall of the device box is provided with a plurality of heat dissipation holes, and the top right side of the inner wall of the device box is fixedly installed with a drive assembly, the drive assembly includes a motor, the top of the motor is fixedly installed with a driving sprocket, the Drive sprocket with three followers
