Technical realization elements of household deodorizer

Technical realization elements:

3. In order to overcome the defects in the prior art, a household deodorizer is provided.

4. The utility model is realized by the following scheme.

5. A household deodorizer, the deodorizer comprising a base, the base and the air intake cover are correspondingly detachably connected, the air intake cover is provided with a plurality of air intake holes correspondingly, the air intake cover The upper end is detachably connected to the air outlet hood, a plurality of air outlet holes are correspondingly provided on the air outlet hood, and an open deodorizing tray is correspondingly provided in the cavity formed by the air inlet hood and the air outlet hood. The top end of the flavor plate is correspondingly connected with the pressure cover, and a filter element is correspondingly provided in the filter element accommodating cavity of the hollow cavity structure composed of the deodorizing plate and the pressure cover.

6. The base includes a base connection disc and a suction cup, the suction cup is a sucker-like structure, and the side wall of the base connection disc is correspondingly provided with threads;

7. A base connecting disc through hole is correspondingly provided in the middle of the air intake cover, and the base connecting disc and the base connecting disc through hole are threaded correspondingly.

8. A number of buckling grooves are correspondingly provided on the inner wall of the air intake cover, and a number of buckling hooks are correspondingly provided at the lower end of the air outlet cover. The buckle hooks match the buckling grooves, and the buckle hooks It can be inserted into the buckle groove correspondingly.

9. Correspondingly are provided with a lower vent hole at the bottom of the deodorizing tray, an upper vent hole is correspondingly provided in the gland, the lower vent hole communicates with the air inlet hole, the upper vent hole and the air outlet hole Corresponding to connectivity.

10. A plurality of lower anti-slip holes are correspondingly provided on the air intake cover, and a plurality of upper anti-slip holes are correspondingly provided on the air outlet cover.

11. The beneficial effects of the present utility model are as follows.

12. The filter element of a household deodorizer of this utility model directly degrades the odor molecules in the refrigerator into harmless small-molecule inorganic substances in the manner of catalytic degradation, purifies the air inside the refrigerator, and removes the odor caused by food spoilage and mildew. The filter element is a nano-active component with high catalytic activity, which can effectively capture odor molecules and quickly decompose them into odorless small molecules. The catalytically active component of the filter element does not change its properties while deodorizing, and can continue to play the deodorizing and deodorizing efficiency for a long time, clean and deodorize, and lasting and safe.
