Technical realization elements of high airtightness adjustable silencer manufacturing device

Technical realization elements:

5. The purpose of this utility model is to address the shortcomings of the prior art and provide a high-airtightness adjustable muffler manufacturing device. Through the manual control of the kneading board movement, the additional block drives the internal length of the transmission unit. The movable rod is close to the gun body, so that the top block on the top of the long movable rod pushes the soft gasket inside the storage chamber and puts it inside the round table at the bottom of the hollow tube, so that when the foam nail moves, the soft gasket is brought into contact with the fixed material. Thereby reducing manual hand-holding and fixing, thereby improving the safety of nailing.

6. In order to achieve the above purpose, the present utility model provides the following technical solutions:

7. A manufacturing device for a high air-tightness adjustable silencer, comprising: a bubble nail unit, a control unit is provided on the right side of the bubble nail unit, and a duct unit is installed at the muzzle of the bubble nail unit, The top of the control unit is equipped with a transmission unit, and the top of the duct unit is equipped with a clamping unit;

8. The control unit includes a mounting column, the bottom end of the mounting column is fixedly connected to the surface on the right side of the bubble nail unit, the bottom end of the mounting column surface is provided with a movable joint, and the top of the movable joint is movably connected with a pinch plate and a pinch plate The bottom of the front end is provided with a telescopic rod, the surface of the telescopic rod is provided with a spring, and an additional block is installed between the top of the spring and the bottom of the front end of the kneading board;

9. When working, hold the pinch plate so that the pinch plate drives the telescopic rod to contract and squeeze the spring.

10. Preferably, the bottom of the bubble nail unit is provided with a gas filling nozzle, and the top of the gas filling nozzle is provided with a gun body.

11. Preferably, the bottom of the middle end of the gun body is provided with a trigger, and the top end of the gun body is provided with a hook.

12. Preferably, the duct unit includes a hollow tube, and the hollow tube is connected to the muzzle position of the gun body through a mounting plate.

13. Preferably, the hollow tube is evenly provided with observation openings along the circumferential direction, and the number of observation openings is four.

14. Preferably, the transmission unit includes a long movable rod, and the left side of the long movable rod is connected to the right side surface of the mounting block.

15. Preferably, the top of the long movable rod is connected with a top block, the bottom of the top block is provided with a storage bin, and the inside of the storage bin is provided with a soft gasket.

16. Preferably, the clamping unit includes a round table, the round table is installed at the bottom of the right side of the hollow tube, the center of the round table is provided with a hollow groove, and the side of the round table near the long movable rod is provided with a straight groove.

17. Preferably, the center of the round table is provided with a restriction port, and the restriction port is concentrically installed at the front end of the muzzle part of the gun body.

18. Preferably, the outer side of the restriction opening is uniformly provided with convex plates along the circumferential direction, and the number of convex plates is four.

19. The beneficial effects of this utility model are:

20. (1) This utility model manually pinches the kneading plate at the top of the mounting column to shrink the kneading plate toward the bottom, so that the kneading plate drives the telescopic rod to move in the same direction, so that the spring on the surface of the telescopic rod deforms. When the deformation is restored, the kneading board is reset, and at the same time, the kneading board's contraction movement will cause the installation block on the top of the spring to drive the transmission unit to move, thereby providing convenience for the subsequent synchronization of adding gaskets.

21. (2) The utility model uses the manual movement of the kneading board to make the additional block drive the long movable rod inside the transmission unit close to the gun body, so that the top block on the top of the long movable rod pushes the soft gasket inside the storage bin to place it To the inside of the round table at the bottom of the hollow tube, it is convenient for the foam nail to drive the soft gasket to contact the fixing material when the foam nail is moving, thereby reducing manual hand-holding and fixing, thereby improving the safety of nailing.

22.(3) The utility model uses the long movable rod to push the soft washer through the top block, it will pass through the straight groove on the side of the round table close to the long movable rod, so that the top block can push the soft washer through the hollow more effectively The groove is transported to the center of the circle surrounded by four convex plates, so that the center of the soft gasket is always right at the muzzle position of the gun body, so that the bubble nail will not be offset when passing through the soft gasket, so Improve the effect of binding.

23. In summary, the utility model has the advantages of high nailing safety and good nailing fixing effect.
