Technical Realization Elements of Heat Treatment Device for Motorcycle Wheel Hub

Technical realization elements:

4. In view of the shortcomings of the prior art, the present utility model provides a motorcycle wheel hub heat treatment device, which solves the problems raised in the background art.

5. In order to achieve the above objectives, the present utility model is achieved through the following technical solutions: a motorcycle wheel heat treatment device, including a bottom plate, the top of the bottom plate is fixedly installed with two supporting plates, and the upper part of the bottom plate is fixedly installed with two supporting plates. There is a waste water tank between two supporting plates, a top plate is fixedly installed on the top of the two supporting plates, the inner fixed sleeve of the top plate is equipped with a spray base, and the outer fixed sleeve of the spray base is provided with a communication interface, on the left side The outside of the support plate is sheathed with a drive motor, the outside of the drive motor is fixedly sheathed with a connecting shaft, the outside of the connecting shaft is slidably clamped with a socket pipe, and the outside of the socket pipe is fixedly installed with a fixing clip, and The inner part of the sleeve pipe is fixedly sleeved with a spring, the inner part of the support plate on the right side is fixedly sleeved with a telescopic base, the inner part of the telescopic base is fixedly sleeved with a telescopic column through a bearing, and the outer part of the telescopic column is fixedly installed with a fixing clip.

6. Optionally, the waste water tank is arranged under the fixing clip on the left side, and a water outlet is opened on the outside of the waste water tank.

7. Optionally, the outside of the fixing clip is provided with evenly distributed through circular holes, and the fixing clip is made of metal.

8. Optionally, the end of the spray base extends to the bottom of the top plate, and the bottom of the spray base is fixedly sleeved with evenly distributed spray heads.

9. Optionally, one end of the spring is fixedly connected to the outside of the fixing clip, and the other end of the spring is fixedly connected to the outside of the connecting shaft.

10. Optionally, the height value of the telescopic column corresponds to the height value of the connecting shaft, and the width value of the fixing clip is smaller than the value of the distance between the waste water tank and the nozzle.

11. The utility model provides a heat treatment device for motorcycle wheels, which has the following beneficial effects:

12.1. The motorcycle hub heat treatment device, through the use of the fixing clip and the sleeve pipe, the connecting shaft and the spring, makes the motorcycle hub heat treatment device expand and contract the base when the motorcycle hub heat treatment device is clamped by the fixing clip.

Start to extend the inner telescopic column, so that the right fixing clip contacts the left fixing clip and clamps the hub. After the two fixing clips contact, the left fixing clip drives the sleeve tube to slide outside the connecting shaft, and at the same time The compression spring makes the hub between the two fixing clamps stable to be clamped, so that the motorcycle hub heat treatment device can effectively protect the hub from damage during clamping.

13.2 The motorcycle hub heat treatment device, through the use of the connection interface and the spray base, and the nozzle and the fixing clip, enables the spray base of the motorcycle hub heat treatment device to communicate with the external heat treatment agent through the connection interface, and introduce the heat treatment agent Then spray through the nozzle, and at the same time the drive motor starts to drive the connecting shaft to rotate, so that the connecting shaft drives the sleeve tube and the fixing clip to rotate, so that the hub clamped between the two fixing clips can rotate. Evenly distributed through holes, so the heat treatment agent can contact the hub through the holes to complete the heat treatment operation of the hub, so that the motorcycle hub heat treatment device has a more uniform heat treatment effect on the hub.
