Technical realization elements of fixtures for wire harness processing

Technical realization elements:

4. The purpose of the present utility model is to provide a fixture for wire harness processing to solve the problem that the existing fixture for wire harness processing operations proposed in the background art is relatively complicated in operation, low in efficiency, and cannot be well applied to wire harnesses. Problems such as processing operations at both ends.

5. In order to achieve the above object, the present invention provides the following technical solution: a clamp for wire harness processing, comprising a fixing plate one, the fixing plate one is provided with a circular through hole in the middle position near the top end, the circular The inside of the through hole is clamped with two rocker bars, the top of the two rocker bars is fixedly installed with a fixed splint, and the middle of the side of the fixed splint away from the two rocker bars is fixedly installed with a fixed disc, and the outer surface of the fixed disc A card slot is provided in the middle of the card slot, a card block is clamped inside the card slot, a gear is fixedly installed on the outer surface of the card block, a rack is meshingly connected to both sides of the gear, and the top of the rack is fixedly installed There is a movable splint, the outer surface of the gear is fixedly installed with a rocker one, a fixed plate two is arranged under the fixed disc, and a groove is arranged at the top of the fixed plate two.

6. Preferably, the outer surface of the fixed disc is attached to the inner wall of the groove, and the fixed splint, the second rocker and the fixed disc are fixedly connected by welding.

7. Preferably, the two end angles of the upper and lower end faces of the fixed splint close to the two sides of the rocker are fixedly installed with guide rods, and the two end angles of the movable splint away from the rack are fixedly installed with The fixed block, the outer surface of the guide rod is clamped in the inner wall of the fixed block.

8. Preferably, the bottom ends of the fixing plate one and the fixing plate two are both provided with mounting plates, and the mounting plates are located at the same level.

9. Preferably, both the upper and lower end surfaces of the fixed splint and the surface of the movable splint close to the fixed splint are provided with circular arc grooves.

10. Preferably, the movable splint and the rack are fixedly connected by welding, the gear, the rocker one and the clamping block are fixedly connected by welding, and the outer surface of the clamping block is clamped in the inner wall of the clamping groove.

11. Compared with the prior art, the beneficial effect of the present utility model is that the fixture for wire harness processing is provided with two

A movable splint can process two sets of wire harnesses at the same time to improve work efficiency. By setting a fixed disc and a rocker, the entire fixture can be turned over. By setting a gear and a rack, it is convenient to adjust the fixed splint and the two movable splints at the same time. Spacing, simple and convenient operation.
