Technical realization elements of edge trimming device for corrugated board processing

Technical realization elements:

3. In view of the above situation, in order to overcome the defects of the prior art, this utility model provides an edge trimming device for corrugated cardboard processing, which effectively solves the inconvenience of trimming corrugated cardboard of different specifications with the current edge trimming device for corrugated cardboard processing. As well as the inconvenience of fixing corrugated cardboard, the edge trimming device for corrugated cardboard processing is convenient to trim corrugated cardboard of different specifications and facilitates the purpose of fixing corrugated cardboard. It is a very practical edge trimming for corrugated cardboard processing. Device.

4. The technical scheme adopted by this utility model is as follows: this utility model is an edge trimming device for corrugated cardboard processing, including a supporting base, a hydraulic rod stand, a lifting hydraulic rod, a movable fixed plate, a rotating shaft of a placing table, and a corrugated cardboard placing table And a mobile pruning device, the hydraulic rod is erected on a support base, the lifting hydraulic rod is arranged on the hydraulic rod stand, the movable fixing plate is arranged on the lifting hydraulic rod, and the rotation axis of the placing table is arranged on the support On the base, the corrugated cardboard placement table is set on the rotation axis of the placement table, the mobile trimming device is set on the support base, and the mobile trimming device includes a bottom plate chute, a stand slider, a support stand, a drive motor, The drive screw, the screw support, the moving slide, the moving slide, the moving connecting plate, the telescopic hydraulic rod, the trimming scissors connecting plate and the moving trimming scissors, the bottom plate slide is provided on the supporting base, and the vertical slide is provided On the bottom plate chute, the support stand is erected on the stand slider, the drive motor is provided on the support stand, the drive screw is provided on the drive motor, and the screw support is provided on the drive screw, The moving chute is arranged on the support stand, the moving sliding block is arranged on the moving sliding groove, the moving connecting plate is arranged on the moving sliding block, the telescopic hydraulic rod is arranged on the moving connecting plate, the The trimming shears connecting plate is set on the telescopic hydraulic rod, the mobile trimming shears are set on the trimming shears connecting plate, the hydraulic rod stand is used to support the lifting hydraulic rod, and the lifting hydraulic rod is used for telescoping to move and fix The board moves, the function of the movable fixed board is to move and fix the corrugated cardboard, the rotation axis of the placing table rotates to drive the corrugated cardboard placement table to rotate, the function of the corrugated cardboard placement table is to facilitate the placement of corrugated cardboard, the The function of the bottom plate chute is to facilitate the placement of the stand slider. The stand slide is to move and drive the support stand, the support stand is to support the drive motor, and the drive screw is to rotate and drive the movement. The sliding block and the moving connecting plate move, the screw support is to support the transmission screw, the moving chute is to place the moving sliding block, and the moving sliding block works

It is used to move and drive the mobile connecting plate, the function of the mobile connecting plate is to move and drive the telescopic hydraulic rod, the function of the telescopic hydraulic rod is to telescopically drive the trimming scissors connecting plate and the mobile trimming scissors to move, the role of the trimming scissors connecting plate It is connected with the telescopic hydraulic rod and the mobile trimming scissors, and the function of the mobile trimming scissors is to move and trim the corrugated cardboard.

5. Further, the lifting hydraulic rod is arranged between the hydraulic rod stand and the moving fixed plate, the rotation axis of the placing table is provided between the supporting base and the corrugated cardboard placing stand, and the stand sliding block is provided on the bottom plate Between the chute and the support stand, the drive motor is arranged between the support stand and the drive screw, the drive screw is arranged between the drive motor and the screw support, and the moving slide is arranged between the moving chute and the drive screw. Between the movable connecting plates, the movable connecting plate is arranged between the movable sliding block and the telescopic hydraulic rod, the telescopic hydraulic rod is arranged between the movable connecting plate and the connecting plate of trimming scissors, and the connecting plate of trimming scissors is arranged on the telescopic Between the hydraulic lever and the mobile trimming scissors.

6. Further, the hydraulic rod stand and the support base are arranged vertically, the lifting hydraulic rod and the hydraulic rod stand are arranged perpendicularly, the movable fixed plate and the lifting hydraulic rod are arranged perpendicularly, and the placing table rotates The shaft and the supporting base are arranged vertically, the corrugated cardboard placement table and the rotation axis of the placement table are vertically arranged, the transmission screw and the driving motor are vertically arranged, the screw support and the transmission screw are vertically arranged, and the movable connection The plate and the moving sliding block are arranged vertically, the telescopic hydraulic rod and the mobile connecting plate are arranged vertically, the trimming shears connecting plate and the telescopic hydraulic rod are arranged perpendicularly, and the movable trimming shears and the trimming shear connecting plate are arranged vertically.

7. Further, the support base is arranged in a rectangular shape, the hydraulic rod stand is arranged in an l-shape, the movable fixed plate is arranged in a rectangular shape, the corrugated cardboard placing table is arranged in a rectangular shape, and the bottom plate chute is in a rectangular shape Setting, the stand slider is arranged in a rectangular shape, the supporting stand is arranged in a U shape, the moving chute is arranged in a rectangular shape, and the moving sliding block is arranged in a rectangular shape.

8. Further, the bottom plate sliding groove is provided with two groups, and the stand sliding block is provided with two groups.

9. The beneficial effects achieved by the utility model with the above structure are as follows: This proposal is an edge trimming device for corrugated cardboard processing, which effectively solves the inconvenience of trimming corrugated cardboard of different specifications and the inconvenience of the current edge trimming device for corrugated cardboard processing. The problem of fixing corrugated cardboard realizes the purpose of the edge trimming device for corrugated cardboard processing to facilitate trimming of corrugated cardboard of different specifications and to facilitate the fixing of corrugated cardboard. It is a very practical edge trimming device for corrugated cardboard processing.
