Technical realization elements of dust-free and fast cutting equipment for sheet metal based on decoration engineering

Technical implementation elements:

4. The purpose of the present invention is to provide a dust-free and fast cutting equipment for boards based on decorative engineering, so as to solve the problems raised in the above-mentioned background art.

5. In order to achieve the above-mentioned purpose, the present invention provides the following technical solutions: a dust-free and fast cutting equipment based on decorative engineering, comprising a base, two sliding rails are symmetrically installed on both sides of the top of the base, and the two sliding A number of steel balls are evenly installed on the top of the rail, two sliders are slidably connected on one side of the top of the two slide rails, and a worktable is installed on the top of the two sliders, a clamping and fixing mechanism is installed on one side of the top of the worktable, and one side of the base is installed. A fixed column is installed, and a lifting mechanism is installed on one side of the top of the fixed column, a dust removal mechanism is installed on one side of the inner side of the base, and a dust drop hole is opened on one side of the top of the base.

6. Preferably, a column is installed at a corner of the top of the base, a controller is fixedly connected to the top of the column, an alarm light is fixedly connected to one side of the top of the controller, and four anchor bolts are installed at four corners of the bottom of the base.

7. Preferably, the clamping and fixing mechanism includes a movable block, a first hand wheel, a top plate, a positioning plate, a pressing block, a threaded block, a screw, a second hand wheel, a fixed block, an installation groove, a first guide rod and For the first screw rod, an installation slot is provided on the top side of the worktable, and a fixing block is installed on one side of the inner side of the installation slot. At the corner position, the first hand wheel is fixedly connected to the center of one end face of the first screw rod, and the center end of the first screw rod is connected to a movable block through a ball nut, and a positioning plate is installed on the top of the movable block, and the bottom of the positioning plate is connected to the top of the workbench. The two sides of the center of the movable block are respectively movably penetrated by first guide rods, and the two first guide rods are symmetrically installed on both sides of the installation groove.
