Technical realization elements of chamfering planer for woodworking

Technical implementation elements:

3. The utility model overcomes the deficiencies in the above-mentioned technologies, and provides a woodworking chamfering planer, which can easily replace the cutter according to the needs, can adapt to different chamfering operations of woodworking, and can have a good management of the cutter at the same time. , to prevent and reduce the possibility of tool loss.

4. In order to solve the above-mentioned technical problems, the utility model adopts the following technical solutions: a woodworking chamfering planer, comprising a chamfering planer body, one side of the chamfering planer body is provided with a chamfering groove, and the chamfering planer is The body is provided with a roller groove and a tool groove, a roller is arranged in the roller groove, the tool groove is connected with the roller groove and the angle planer groove, a tool is arranged in the tool groove, and the tool is connected with the Removable connection for rollers.

5. The utility model is set in a detachable connection mode through the cutter and the roller, so that when the cutter needs to be replaced, the replacement of the cutter is greatly facilitated, so that the utility model can conveniently replace different types or models of cutters to meet the needs of The need for different tools used in woodworking.

6. Preferably, the tool groove is perpendicular to the roller groove, a connecting hole is provided at one end of the tool close to the roller groove, and a connecting column is provided on the side of the roller close to the tool groove. The connecting column is screwed with the connecting hole.
