Technical realization elements of a protective device after hip replacement

Technical implementation elements:

3. The purpose of this utility model is to provide a protective device after hip replacement in order to solve the above problems. After the u-shaped bracket is fixed on the top of the hospital bed, the curved splint on both sides is driven by the adjustment component to approach each other. The position of the hip joints on both sides of the patient is respectively contacted and protected, which avoids the dislocation of the hip joint caused by accidental movement of the personnel, and at the same time replaces the protection method of winding multiple turns of gauze.

4. for achieving the above object, the utility model provides the following technical solutions:

5. The utility model provides a protective device after hip replacement, including a u-shaped bracket, the u-shaped bracket is set upside down, the vertical parts on both sides of the u-shaped bracket are longitudinally arranged, and both are meshed and connected with edge. a laterally arranged adjustment assembly, the ends of the adjustment assemblies on both sides that are close to each other are located between the vertical parts on both sides of the u-shaped bracket and a protection assembly is installed;

6. The bottom surfaces of the vertical parts on both sides of the u-shaped bracket are fixed with clamping components for fixing the u-shaped bracket on the top of the hospital bed, and the two clamping components are symmetrically distributed.

7. Preferably, the clamping assembly includes a u-shaped socket and a compression stud, the u-shaped sockets of the two clamping components are arranged horizontally and the openings are facing each other, and the two u-shaped sockets are arranged horizontally. The card seats are symmetrically distributed, the bottom of the U-shaped card seat is vertically engaged and connected with the pressing stud, and the top of the pressing stud extending into the corresponding U-shaped card seat is horizontally fixed with a pressing plate and the parts of the pressing stud extending out corresponding to the bottom surface of the u-shaped card seat are engaged and connected with a pressing nut.

8. Preferably, a handle is fixed at the bottom end of the pressing stud extending out corresponding to the bottom surface of the U-shaped card seat, the pressing plate is a circular plate, and an elastic pad is covered and fixed on the top surface of the pressing plate.
