Technical realization elements of a lubricating device for rail maintenance

Technical implementation elements:

5. The purpose of the present invention is to provide a lubricating device for rail maintenance and a method thereof, so as to solve the problems raised in the above-mentioned background art.

6. In order to achieve the above object, the present invention provides the following technical solutions:

7. A lubricating device for rail maintenance, comprising a main groove frame, the main groove frame is erected on a single-sided rail, and a smear component for lubricating the surface of the rail is provided in the main groove frame;

8. The smearing assembly comprises at least one set of oppositely arranged smearing plates arranged at intervals along the moving direction of the main trough frame, each of the smearing plates is arranged on the inner side of the rail for contact with the train wheels, the A gap is reserved between the lubricating plate and the outer surface of the rail, the top surface on the left side of each lubricating plate is rotatably installed with a pressing rod, and a pressing block is fixed on the top of the pressing rod. The top surface of the right side of the plate is provided with a plate arc groove along the radial direction of the main groove frame, and the arc groove block is slidably clamped and connected with the arc groove block. The top of the pressure rod is fixed with a swing pressure block;

9. The inner top of the main slot frame is hoisted with a pressure block press head for pressing down the swing pressure block and the pressing block in turn along the radial movement of the main groove frame. The radial direction reciprocates left and right;

10. A main travel wheel for driving the overall movement of the main slot frame is installed in the axial middle position of the main slot frame. The main travel wheel is driven and rotated by a drive motor installed on the main slot frame. The linkage mechanism drives the cam mechanism to rotate;

11. The lubricating plates arranged oppositely are respectively arranged at the front and rear positions of the main travel wheel, and the left and right reciprocating motion states of the pressing block indenters in the front and rear positions are dislocated;

12. The top of the main tank frame is provided with a lubricating liquid tank for supplying liquid to the coating surface of the lubricating plate, and a main control box is installed on one side of the lubricating liquid tank.
