Technical realization elements of a diagnostic device for allergic diseases

Technical implementation elements:

6. The present invention provides a diagnostic device for allergic diseases to solve the problems raised in the above background art.

7. for solving the above-mentioned technical problems, the technical scheme adopted in the present invention is:

8. A diagnostic device for allergic diseases, comprising a diagnostic bed, a mobile structure is movably connected to the left side of the diagnostic bed, a hydraulic rod is fixedly installed on the top of the mobile structure, and an output end of the hydraulic rod is rotatably connected with a A bridge rod, the bottom of the bridge rod is fixedly installed with an adjustment structure, the bottom of the adjustment structure is fixedly installed with a diagnostic device main body, an annular protective sleeve is fixedly installed at the edge of the diagnostic device main body, and the right end of the bridge rod is installed A telescopic rod is rotatably connected, and a support structure is fixedly installed at the bottom of the telescopic rod.

9. The adjustment structure includes a u-shaped buckle and an annular track plate, the top of the u-shaped buckle is fixedly installed with the bottom of the bridge rod, and the bottom of the annular track plate is fixedly installed on the left side of the upper surface of the main body of the diagnostic device. One side of the U-shaped buckle is movably sleeved with a locking nut, the inner wall of the locking nut is threadedly connected with a stud, one end of the stud is fixedly installed with a spacer plate, and the locking nut is One side of the cap is rotatably connected with a positioning push plate.

10. The support structure includes an elongated support rod, the top of the elongated support rod is fixedly installed with the bottom of the telescopic rod, the bottom of the extended support rod is provided with a connection group, and the bottom of the connection group is fixedly installed with a cylindrical slide. A catheter sleeve, the inner wall of the cylindrical sliding catheter sleeve is slidably connected with a cylindrical sliding guide rail, and a bracket rod is fixedly installed at the bottom of the outer wall of the cylindrical sliding guide rail.
