Technical realization elements of a complete machine cross-line transfer device

Technical implementation elements:

3. The purpose of this technology is to provide a complete machine cross-line transfer device, which can assist the railway tractor to perform the cross-line transfer operation quickly and efficiently.

4. Embodiments of the present technology are implemented as follows:

5. The embodiment of the present technology provides a complete machine cross-line transfer device, which includes a complete machine cross-line transfer support and a lifting device for driving the lift of the complete machine cross-line transfer support. The two ends of the complete machine cross-line transfer support are respectively A steel wheel connecting bracket is connected, and each steel wheel connecting bracket is connected with a rotatable steel wheel and a steel wheel driving motor for driving the corresponding steel wheel to rotate; The axis is rotated 90 degrees, so that the axes of the two corresponding steel wheels are collinear and parallel to the length direction of the cross-line transfer bracket of the whole machine, and the two corresponding steel wheels are coplanar and the axes are parallel to the width of the cross-line transfer support of the whole machine direction.

6. In some optional embodiments, one end of each steel wheel connecting bracket is hinged with the end of the whole machine cross-line transfer support through a connecting pin, and each steel wheel connecting bracket is connected with at least one locking bolt, The locking bolt is configured to be movable in the axial direction to pass through and lock or unlock the drum connecting bracket and the corresponding complete machine cross-line transfer bracket.

7. In some optional embodiments, the side part of each steel wheel connecting bracket is connected with a steel wheel fixing frame, and the side part of the whole machine cross-line transfer bracket is connected with a whole machine corresponding to the steel wheel fixing frame one-to-one. Cross-line connecting frame; when the steel wheel connecting bracket rotates around the connecting pin, the axis of the corresponding steel wheel rotates from the length direction parallel to the whole machine cross-line transfer bracket to the width direction parallel to the whole machine cross-line transfer bracket, and the locking bolt is set. It is configured to be movable in the axial direction to pass through and to lock or unlock the drum holder and the whole machine jumper connection frame.
