Technical realization elements for efficient installation of equipment on square shaft of linkage valve blades

Technical realization elements:

3. The purpose of this utility model is to provide an efficient installation equipment for the square shaft of the linked valve blade, which solves the problem that the traditional installation method in the prior art still uses a manual hand-held mace to fit the square shaft into the blade, and the installation efficiency is relatively high. Low question.

4. In order to achieve the above objective, the present utility model provides an efficient installation equipment for the square shaft of the linked valve blades. The efficient installation equipment for the square shaft of the linked valve blades includes a housing, a first partition, a second partition, and a push Component, the housing is provided with the first partition and the second partition in sequence from left to right, and the first partition and the second partition divide the housing from left to right The right is sequentially divided into a first placement area, a second placement area, and a third placement area. Both sides of the first placement area are provided with a first clamping assembly, and the second placement area is provided with a second clamp. Holding assembly, the pushing assembly is arranged in the third placement area, a first through hole is arranged on the second partition, and the first through hole corresponds to the output end of the pushing assembly. A second through hole is provided on the first partition.

5. The blade is fixed in the first placement area by two of the first clamping components, so that the installation piece of the blade corresponds to the second through hole, and the square shaft is clamped by the second holding component Is held in the second placement area so that both ends of the square shaft correspond to the first through hole and the second through hole, and the pushing assembly is activated to install the square shaft in the blade. higher efficiency.

6. The pushing assembly includes an oil cylinder, a pushing shaft, and a pushing plate. The mounting end of the oil cylinder is detachably connected to the housing and is located at an end of the third placement area away from the second placement area, so The output end of the oil cylinder is provided with the pushing shaft, the pushing shaft penetrates the first through hole, the pushing plate is detachably connected with the pushing shaft, and is located at an end of the pushing shaft away from the oil cylinder.

7. Preferably, the second clamping assembly includes a mounting plate, a support plate and a clamping ring, the mounting plate is detachably connected to the housing and is located in the second placement area, and the support plate One end is fixedly connected with the mounting plate, and the other end of the supporting plate is fixedly connected with the clamping ring.

8. Preferably, the clamping ring includes a first half ring and a second half ring, the first half ring is fixedly connected to the support plate, and two of the first half ring and the second half ring are Both ends are provided with connecting blocks, and the connecting blocks on the first half ring are bolted to the connecting blocks on the second half ring.

9. After placing the square shaft inside the first half ring, cover the second half ring, and fix the two connecting blocks with bolts to fix the position of the square shaft and push it through the cylinder In the case of a square shaft, the square shaft always corresponds to the second through hole.

10. Each of the two first clamping components includes a threaded column, a resisting plate and an adjusting nut, both sides of the first placement area are provided with through holes, and the threaded column penetrates the corresponding through hole, One end of the threaded column is fixedly connected with the resisting plate, and the other end of the threaded column is sleeved with the adjusting nut.

11. A first placement frame and a second placement frame are respectively provided on both sides of the first placement area, and both the first placement frame and the second placement frame are provided with a hollow structure.

12. Preferably, one side of the second placement area is provided with a third placement frame, and the third placement frame is set in a grid structure. The third placement frame is provided on one side of the second placement area, and multiple square shafts can be placed in the third placement frame. The third placement frame is set in a grid structure, which saves materials. At the same time, avoid falling of the square shaft.

13. The housing includes a bottom plate, two side plates, and two end plates, both of the side plates are fixedly connected to the bottom plate and are located on both sides of the bottom plate, and both of the end plates are It is fixedly connected with the bottom plate and is located at both ends of the bottom plate respectively. Both the side plate and the end plate are fixedly connected with the bottom plate, and the integral molding technology is adopted to make the structure more firm during manufacture.

14. The utility model relates to an efficient installation equipment for the square shaft of linked valve blades. The first partition and the second partition separate the housing from left to right into a first placement area and a second partition. A placement area and a third placement area, the first placement area is provided with first clamping components on both sides, the second placement area is provided with a second clamping assembly, and the third placement area is provided There is the pushing component, and the blade is fixed in the first placement area by the two first clamping components, so that the installation piece of the blade corresponds to the second through hole, and the second holding component is used Clamp the square shaft in the second placement area so that both ends of the square shaft correspond to the first through hole and the second through hole respectively, and activate the pushing assembly to install the square shaft in In the blade, the installation efficiency is higher.
